10.1inch LCD touch screen 1920*1200 LVDS interface 1400 brightness LCD module Military screen
香港
| 生產線所在地：中國內地
展位編號: 5B-D08 | 顯示技術世界 |
產品規格
是否可訂造
可以
型號編號
MTF101UG49A-V1
品牌
Microtech
尺寸
10.1inch
產品簡介
NO | Item | Specification | Remark |
1 | LCD Size | 10.1 inch (Diagonal) | |
2 | Driver element | a-Si TFT active matrix | |
3 | Resolution | 1920(H) x3(RGB)x 1200(V) | |
4 | Display mode | Normally Black, Transmissive | |
5 | Dot pitch | 0.03764(H) X RGB X 0.11292(V) | |
6 | Active area | 217.65(H)*136.0(V) | |
7 | Module size | 229.46(W) x149.35(H) x4.6 (D)mm | Note 1 |
8 | Surface treatment | Anti-Glare | |
9 | Color arrangement | RGB-stripe | |
10 | Interface | LVDS | |
11 | Backlight power consumption | 6720 | mW |
12 | Panel power consumption | 660(Typ.) | mW |
13 | Weight | TBD |
生產所需時間
25-45 日
