Features<ul><li>Dimmable by DALI-2 DT8 and Push-DIM &amp; ColorSwitch</li><li>3%-100% dimming range</li><li>Looping of Primary: DALI &amp; Push-DIM</li><li>Constant current output independent led driver</li><li>Adjustable output current by dip switches from 350mA to 1100mA</li><li>EcoDesign Directive (EU) 2019/2020 compliant</li><li>Tool-less installation and with through wiring</li><li>Permanent memory for DALI &amp; Push dimming</li><li>Working Ta=-20°C ~ +50°C</li><li>Reliable, Class II, SELV according EN 61347</li><li>Five-year factory guarantee and lifetime technical support</li></ul>Benefits<ul><li>Adjustable output current for less inventory</li><li>Energy savings due to standby power&lt;0.5W</li><li>Through wiring</li><li>Quick and easy installation without tool</li></ul> Connection Interfaces<ul><li>DALI DT8, DALI DT6</li><li>Push-DIM &amp; Colorswitch</li><li>AUX 12V 100mA Max.</li><li>Strain relief with through wiring function</li><li>Terminal blocks: pus- fit terminals</li></ul> Protection Functions<ul><li>Over current</li><li>Over voltage</li><li>Short circuit</li><li>Over temperature</li></ul>Application<ul><li>For Tunable White as well as for 2-channel use (e.g. warm white/cool white; direct/indirect lighting)</li><li>For panel light, troffer and area light in office and education application</li><li>For spot light and downlight in retail and hospitality applications</li></ul> Others<ul><li>Certification: ENEC, DALI, ETL, FCC, CE, TUV, RoHS, SAA</li><li>Wattage Seletable(W): 3W to 150W</li><li>PFC 0.95</li><li>Customized: Yes</li><li>Warranty: 5 year</li><li>MOQ: 500</li></ul>

A revolution in spotlights with <span style="color: rgb(65, 65, 65); font-family: sans-serif; font-size: 14px; font-style: normal; font-variant-ligatures: normal; font-variant-caps: normal; font-weight: 400; letter-spacing: normal; orphans: 2; text-align: left; text-indent: 0px; text-transform: none; white-space: normal; widows: 2; word-spacing: 0px; -webkit-text-stroke-width: 0px; background-color: rgb(255, 255, 255); text-decoration-thickness: initial; text-decoration-style: initial; text-decoration-color: initial; display: inline !important; float: none;">AiScene™&nbsp;Technology revolutionizes retail lighting. By mimicking the full-body spectrum of daylight and enhancing the colours with high color saturation. AiScene™ technology brings out the richest reds, whiter whites, vibrant blues and all colors of merchandise that “pop” automatically &amp; autonomously. &nbsp;<h3 style="margin-top:5.0pt;margin-right:0cm;margin-bottom:0cm;margin-left: 21.0pt;margin-bottom:.0001pt;mso-para-margin-top:5.0pt;mso-para-margin-right: 0cm;mso-para-margin-bottom:0cm;mso-para-margin-left:2.0gd;mso-para-margin-bottom: .0001pt;layout-grid-mode:char;mso-layout-grid-align:none;vertical-align:baseline;"> </h3><h3 style="margin-top:5.0pt;margin-right:0cm;margin-bottom:0cm;margin-left: 21.0pt;margin-bottom:.0001pt;mso-para-margin-top:5.0pt;mso-para-margin-right: 0cm;mso-para-margin-bottom:0cm;mso-para-margin-left:2.0gd;mso-para-margin-bottom: .0001pt;layout-grid-mode:char;mso-layout-grid-align:none;vertical-align:baseline;">What's the difference of AiScene™ technology？</h3><h3 style="margin-top:0cm;margin-right:0cm;margin-bottom:0cm;margin-left:21.0pt; margin-bottom:.0001pt;mso-para-margin-top:0cm;mso-para-margin-right:0cm; mso-para-margin-bottom:0cm;mso-para-margin-left:2.0gd;mso-para-margin-bottom: .0001pt;layout-grid-mode:char;mso-layout-grid-align:none;vertical-align:baseline;">EYES PERCEIVED RICHEST COLORS BY FULL SPECTRUM</h3><ul style="margin-left: 56px; list-style-type: disc;"><li style="vertical-align: baseline;">Colors enhanced &amp; “POP”</li><li style="vertical-align: baseline;">Reds looks red; blues looks blue, delivers whiter whites, etc.</li></ul><h3 style="margin-top:0cm;margin-right:0cm;margin-bottom:0cm;margin-left:21.0pt; margin-bottom:.0001pt;mso-para-margin-top:0cm;mso-para-margin-right:0cm; mso-para-margin-bottom:0cm;mso-para-margin-left:2.0gd;mso-para-margin-bottom: .0001pt;layout-grid-mode:char;mso-layout-grid-align:none;vertical-align:baseline;">AUTOMATICALLY &amp; AUTONOMOUSLY COLOR SENSING &amp; ENHANCEMENT</h3><ul style="margin-left: 56px; list-style-type: disc;"><li style="vertical-align: baseline;">All in one light spectrum with automatically control to enhance color of merchandise</li><li style="vertical-align: baseline;">Real time spectrum can autonomously manipulate according to merchandise color</li></ul>&nbsp; &nbsp;What's the benefits of AiScene™ technology？<h3 style="margin-top:0cm;margin-right:0cm;margin-bottom:0cm;margin-left:21.0pt; margin-bottom:.0001pt;mso-para-margin-top:0cm;mso-para-margin-right:0cm; mso-para-margin-bottom:0cm;mso-para-margin-left:2.0gd;mso-para-margin-bottom: .0001pt;layout-grid-mode:char;mso-layout-grid-align:none;vertical-align:baseline;">ENHANCE SHOPPING EXPERIENCE</h3><ul style="margin-left: 56px; list-style-type: disc;"><li style="vertical-align: baseline;">Make your store more attractive to improve customer and employee satisfaction</li><li style="vertical-align: baseline;">Create zones by varying lighting to highlight different displays around the store</li><li style="vertical-align: baseline;">Build your brand presence with the right balance of lighting for maximum impact</li></ul>ENGAGE CUSTOMERS &amp; SALES<ul style="margin-left: 56px; list-style-type: disc;"><li style="vertical-align: baseline;">Guide customers through your store, and increase the average spend per customer</li><li style="vertical-align: baseline;">Direct shoppers to key merchandise and affect how they perceive your overall business.</li><li style="vertical-align: baseline;">Collect data on how your customers shop so you can optimize store layout</li></ul>

The DALI controller converts a DALI or Push signal to phase-cut dimming. It can be used where you want a phase-cut dimmable luminaire in a DALI system. This DALI trailing edge phase dimmer can be used with many common, dimmable, line voltage LED lamps, high voltage halogen and incandescent lamps and electronic transformers. &nbsp;It can realize savings on installation and wiring costs and will also reduce unnecessary waste of electronic equipment, making it an environmentally sound solution for a lighting control upgrade.With immunity to EN 61547, safety to EN 61347 and providing protection from over temperature, short-circuit and overload (electronically reversible), this is a high quality product that will give you reliable protection and service. Its standby power consumption is &lt;0.50 W.Features<ul style="list-style-type: disc;"><li align="left" style="text-align:left;">DALI DT6/Push dim to the leading edge, trailing edge; and also DALI DT6 to Kinglumi TTW tunable white</li><li align="left" style="text-align:left;">Automatic detection of load type</li><li align="left" style="text-align:left;">Automatic switch to either leading or trailing edge</li><li align="left" style="text-align:left;">Max. load 3- 400W for resistive; 3-300W for leading &amp; trailing; 3-200W for TTW</li><li align="left" style="text-align:left;">Dimming range: 10%-100%</li><li align="left" style="text-align:left;">Take only one DALI address to control several dimming luminaires/lamps</li><li align="left" style="text-align:left;">Built--in with permanent memory</li><li align="left" style="text-align:left;">Suitable for both retrofit and new installations</li><li align="left" style="text-align:left;">Working Ta=0°C ~ +50°C</li><li align="left" style="text-align:left;">Five-year factory guarantee and lifetime technical support</li><li align="left" style="text-align:left;">The phase dimmed output has a DALI Short Address, and can be including in up to 16 DALI Group Addresses and/or up to 16 DALI Scenes.</li></ul>Benefits<ul><li align="left" style="text-align:left;">Less DALI address, easier for DALI commissioning and wiring</li><li align="left" style="text-align:left;">Save you time and money thanks to the easy installation and less products cost</li><li align="left" style="text-align:left;">Energy savings due to standby power&lt;0.50W</li><li align="left" style="text-align:left;">Quick and easy installation</li><li align="left" style="text-align:left;">Min. cut-out hole diameter 66mm for recessed downlights</li></ul>Connection Interfaces<ul><li align="left" style="text-align:left;">DALI, Push-DIM</li><li align="left" style="text-align:left;">Strain relief with through wiring function</li><li align="left" style="text-align:left;">Terminal blocks: pus- fit terminals</li></ul>Protection Functions<ul><li align="left" style="text-align:left;">Over current &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp;&nbsp;</li><li align="left" style="text-align:left;">Over voltage &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp;</li><li align="left" style="text-align:left;">Short circuit &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp;</li><li align="left" style="text-align:left;">Over temperature</li></ul>Application<ul><li align="left" style="text-align:left;">Suitable for dimmable high voltage LED lamps, fluorescent lamps, halogen and incandescent lamps</li><li align="left" style="text-align:left;">Suitable for all Kinglumi TTW products with tunable white function</li><li align="left" style="text-align:left;">Commercial Buildings, Hotels, Health Care facilities, Education facilities, Museums, Art Galleries, Homes.</li></ul>

LEDGEAR® C9, the most compact design DALI-2 looping LED driver in the world, which covering all the wattage within 22W (500mA) for indoor lighting, especially suitable for cut out hole no less than 66mm, and bigger but with small ceiling void.The driver equipped with push-fit terminals, which enable through wiring of Primary, DALI and Push wires throughout the driver, and save lots of time and effort on a site’s actual wiring work. The terminals allow quick cable connections without any tool, and also support a variety of wire gauge and cable thicknesses. Assembled with 4xDIP switches, the driver allows output current selectable, or programmed any output current by DALI. Variable output voltage of 14-40V with constant current output. These wide operating windows and easy wiring for LED modules makes it super flexibility and warehouse inventory reduction. &nbsp; &nbsp; &nbsp;Product description<ul><li>Design DALI-2 &amp; Push-DIM 2in1 dimming</li><li>Min. cut-out hole diameter 66mm for recessed downlights</li><li>Reliable, Class II, SELV according EN 61347</li><li>ENEC, CE, CB approved by TUV SUD, SAA, C-tick qualified</li><li>Eco Design Directive (EU) 2019/2020 compliant</li><li>Tool-less installation and with through wiring</li><li>ENHANCED amplitude dimming technology</li><li>±5% output current accuracy(under maximum load)</li><li>Protection for output open load, short circuits, over voltage and over temperature</li><li>Built--in with permanent memory for DALI and Push-DIM, 100,000 times memory</li><li>80°C Maximum case operation temperature(tc-point ¹)</li><li>Operating temperature ¹: -25°C ~ +55°C, the humidity: 20% ~ 85%</li><li>Over 55,000 hrs nominal lifespan at tc=65°C</li><li>Five-year factory guarantee and lifetime technical support ¹</li><li>“¹” Detailed data please refer to the " PARAMETERS" table .</li></ul>Features &amp; Benefits&nbsp; &nbsp; &nbsp; Flexibility &amp; Optimized Inventory<ul><li>Both model covers wattages from 4.8W to 19W and differs in lifespan</li><li>Wattage selectable by 3xDIP switches.</li><li>Push-fit secondary terminals for LED module wires</li></ul>&nbsp; &nbsp; &nbsp;Human Centric Design<ul><li>Easy &amp; Quick connection with push-fit terminals and clip-on end cap for strain relief, super large wiring space</li><li>Loop in &amp; loop out function, max.2.5mm2 cross section L, L, N, N, DA, DA,DA,DA stranded wire or solid wire</li><li>Loose wiring inspection don't need to open the transparent end cap</li></ul>Connection Interfaces<ul><li>DALI DT6, Push-DIM</li><li>Strain relief with through wiring function</li><li>Terminal blocks: push- fit terminals</li></ul>Housing Properties<ul><li>Casing: polycarbonate, white</li><li>Type of protection IP20</li></ul>Typical applications<ul><li>For downlight and spot light in both residential, commercial and decorative lighting applications</li></ul>

<p style="margin: 0px 0px 10px; padding: 0px; font-size: 12px; font-family: Arial, 微软雅黑, sans-serif; vertical-align: baseline; line-height: 22px; color: rgb(0, 0, 0); font-style: normal; font-variant-ligatures: normal; font-variant-caps: normal; font-weight: 400; letter-spacing: normal; orphans: 2; text-indent: 0px; text-transform: none; white-space: normal; widows: 2; word-spacing: 0px; -webkit-text-stroke-width: 0px; text-decoration-thickness: initial; text-decoration-style: initial; text-decoration-color: initial; text-align: justify;">These DALI (EN 62386-207: device type 6) dimmable LED track lights come to provide the proper illumination that's needed to emphasize a certain objects in a favorable way. With ability to alter the power output accordingly, it can provide the ideal accent and general lighting while reducing power consumption effectively. The innovative track light can be adjusted freely with 350° horizontal rotation and 90° vertical tilt, making it ideal for producing the perfect lighting according to needs of specific lighting situations.<p style="margin: 0px; padding: 0px; font-size: 12px; font-family: Arial, 微软雅黑, sans-serif; vertical-align: baseline; line-height: 22px; color: rgb(0, 0, 0); font-style: normal; font-variant-ligatures: normal; font-variant-caps: normal; font-weight: 400; letter-spacing: normal; orphans: 2; text-indent: 0px; text-transform: none; white-space: normal; widows: 2; word-spacing: 0px; -webkit-text-stroke-width: 0px; text-decoration-thickness: initial; text-decoration-style: initial; text-decoration-color: initial; text-align: justify;">With the 6 wires 3 circuits track adapters, It’s designed to integrate with three different DALI track systems of GLOBAL Trac Pulse. Our unique DALI dimming track lights are the perfect solution to achieve proper dimming for optimizing the appearance of objects being illuminated as well as increasing the longevity of light fittings. Such Dimming LED track light is also available in four interchangeable lens of 15°, &nbsp;38°, 60°, offering flexibility of generating desired lighting easily and in the meantime saving replacement costs.<p style="margin: 0px; padding: 0px; font-size: 12px; font-family: Arial, 微软雅黑, sans-serif; vertical-align: baseline; line-height: 22px; color: rgb(0, 0, 0); font-style: normal; font-variant-ligatures: normal; font-variant-caps: normal; font-weight: 400; letter-spacing: normal; orphans: 2; text-indent: 0px; text-transform: none; white-space: normal; widows: 2; word-spacing: 0px; -webkit-text-stroke-width: 0px; text-decoration-thickness: initial; text-decoration-style: initial; text-decoration-color: initial; text-align: justify;"> <p style="margin: 0px; padding: 0px; font-size: 12px; font-family: Arial, 微软雅黑, sans-serif; vertical-align: baseline; line-height: 22px; color: rgb(0, 0, 0); font-style: normal; font-variant-ligatures: normal; font-variant-caps: normal; font-weight: 400; letter-spacing: normal; orphans: 2; text-indent: 0px; text-transform: none; white-space: normal; widows: 2; word-spacing: 0px; -webkit-text-stroke-width: 0px; text-decoration-thickness: initial; text-decoration-style: initial; text-decoration-color: initial; text-align: justify;">Applications:&nbsp;Retail stores, shopping centers, hotels, auto dealerships, art-gallery and museums, residences, just to speak a few.&nbsp;<p style="margin: 0px; padding: 0px; font-size: 12px; font-family: Arial, 微软雅黑, sans-serif; vertical-align: baseline; line-height: 22px; color: rgb(0, 0, 0); font-style: normal; font-variant-ligatures: normal; font-variant-caps: normal; font-weight: 400; letter-spacing: normal; orphans: 2; text-indent: 0px; text-transform: none; white-space: normal; widows: 2; word-spacing: 0px; -webkit-text-stroke-width: 0px; text-decoration-thickness: initial; text-decoration-style: initial; text-decoration-color: initial; text-align: justify;"> <p style="margin: 0px; padding: 0px; font-size: 12px; font-family: Arial, 微软雅黑, sans-serif; vertical-align: baseline; line-height: 22px; color: rgb(0, 0, 0); font-style: normal; font-variant-ligatures: normal; font-variant-caps: normal; font-weight: 400; letter-spacing: normal; orphans: 2; text-indent: 0px; text-transform: none; white-space: normal; widows: 2; word-spacing: 0px; -webkit-text-stroke-width: 0px; text-decoration-thickness: initial; text-decoration-style: initial; text-decoration-color: initial; text-align: justify;"> <p style="margin: 0px 0px 10px; padding: 0px; font-size: 12px; font-family: Arial, 微软雅黑, sans-serif; vertical-align: baseline; line-height: 22px; color: rgb(0, 0, 0); font-style: normal; font-variant-ligatures: normal; font-variant-caps: normal; font-weight: 400; letter-spacing: normal; orphans: 2; text-align: start; text-indent: 0px; text-transform: none; white-space: normal; widows: 2; word-spacing: 0px; -webkit-text-stroke-width: 0px; text-decoration-thickness: initial; text-decoration-style: initial; text-decoration-color: initial;">FEATURES:&nbsp;<p style="margin: 0px 0px 5px; padding: 0px; font-size: 12px; font-family: Arial, 微软雅黑, sans-serif; vertical-align: baseline; line-height: 22px; color: rgb(0, 0, 0); font-style: normal; font-variant-ligatures: normal; font-variant-caps: normal; font-weight: 400; letter-spacing: normal; orphans: 2; text-indent: 0px; text-transform: none; white-space: normal; widows: 2; word-spacing: 0px; -webkit-text-stroke-width: 0px; text-decoration-thickness: initial; text-decoration-style: initial; text-decoration-color: initial; text-align: left;">•&nbsp;Patented CAMETA high-quality lens design contributing to glare-free and uniform lighting.<p style="margin: 0px 0px 5px; padding: 0px; font-size: 12px; font-family: Arial, 微软雅黑, sans-serif; vertical-align: baseline; line-height: 22px; color: rgb(0, 0, 0); font-style: normal; font-variant-ligatures: normal; font-variant-caps: normal; font-weight: 400; letter-spacing: normal; orphans: 2; text-indent: 0px; text-transform: none; white-space: normal; widows: 2; word-spacing: 0px; -webkit-text-stroke-width: 0px; text-decoration-thickness: initial; text-decoration-style: initial; text-decoration-color: initial; text-align: left;">• DALI dimmable track light, compatible with GLOBAL Trac Pulse<p style="margin: 0px 0px 5px; padding: 0px; font-size: 12px; font-family: Arial, 微软雅黑, sans-serif; vertical-align: baseline; line-height: 22px; color: rgb(0, 0, 0); font-style: normal; font-variant-ligatures: normal; font-variant-caps: normal; font-weight: 400; letter-spacing: normal; orphans: 2; text-align: start; text-indent: 0px; text-transform: none; white-space: normal; widows: 2; word-spacing: 0px; -webkit-text-stroke-width: 0px; text-decoration-thickness: initial; text-decoration-style: initial; text-decoration-color: initial;">• Available in interchangeable lens of 15°,38°, 60° for suiting the needs of multiple lighting distributions<p style="margin: 0px; padding: 0px; font-size: 12px; font-family: Arial, 微软雅黑, sans-serif; vertical-align: baseline; line-height: 22px; color: rgb(0, 0, 0); font-style: normal; font-variant-ligatures: normal; font-variant-caps: normal; font-weight: 400; letter-spacing: normal; orphans: 2; text-align: start; text-indent: 0px; text-transform: none; white-space: normal; widows: 2; word-spacing: 0px; -webkit-text-stroke-width: 0px; text-decoration-thickness: initial; text-decoration-style: initial; text-decoration-color: initial;">• Adjusted 350° horizontally and 90° vertically for the proper illumination<p style="margin: 0px; padding: 0px; font-size: 12px; font-family: Arial, 微软雅黑, sans-serif; vertical-align: baseline; line-height: 22px; color: rgb(0, 0, 0); font-style: normal; font-variant-ligatures: normal; font-variant-caps: normal; font-weight: 400; letter-spacing: normal; orphans: 2; text-align: start; text-indent: 0px; text-transform: none; white-space: normal; widows: 2; word-spacing: 0px; -webkit-text-stroke-width: 0px; text-decoration-thickness: initial; text-decoration-style: initial; text-decoration-color: initial;">• Equipped with aluminum thermal design featuring excellent heat conductivity<p style="margin: 0px; padding: 0px; font-size: 12px; font-family: Arial, 微软雅黑, sans-serif; vertical-align: baseline; line-height: 22px; color: rgb(0, 0, 0); font-style: normal; font-variant-ligatures: normal; font-variant-caps: normal; font-weight: 400; letter-spacing: normal; orphans: 2; text-align: start; text-indent: 0px; text-transform: none; white-space: normal; widows: 2; word-spacing: 0px; -webkit-text-stroke-width: 0px; text-decoration-thickness: initial; text-decoration-style: initial; text-decoration-color: initial;">• High CRI 90 with up to 110lm/W system efficacy<p style="margin: 0px; padding: 0px; font-size: 12px; font-family: Arial, 微软雅黑, sans-serif; vertical-align: baseline; line-height: 22px; color: rgb(0, 0, 0); font-style: normal; font-variant-ligatures: normal; font-variant-caps: normal; font-weight: 400; letter-spacing: normal; orphans: 2; text-align: start; text-indent: 0px; text-transform: none; white-space: normal; widows: 2; word-spacing: 0px; -webkit-text-stroke-width: 0px; text-decoration-thickness: initial; text-decoration-style: initial; text-decoration-color: initial;">• Come with finishes of black, white<p style="margin: 0px; padding: 0px; font-size: 12px; font-family: Arial, 微软雅黑, sans-serif; vertical-align: baseline; line-height: 22px; color: rgb(0, 0, 0); font-style: normal; font-variant-ligatures: normal; font-variant-caps: normal; font-weight: 400; letter-spacing: normal; orphans: 2; text-align: start; text-indent: 0px; text-transform: none; white-space: normal; widows: 2; word-spacing: 0px; -webkit-text-stroke-width: 0px; text-decoration-thickness: initial; text-decoration-style: initial; text-decoration-color: initial;">• Complete with accessories of Barndoor, Snoot, Honeycomb, Oval Snoot.<p style="margin: 0px; padding: 0px; font-size: 12px; font-family: Arial, 微软雅黑, sans-serif; vertical-align: baseline; line-height: 22px; color: rgb(0, 0, 0); font-style: normal; font-variant-ligatures: normal; font-variant-caps: normal; font-weight: 400; letter-spacing: normal; orphans: 2; text-align: start; text-indent: 0px; text-transform: none; white-space: normal; widows: 2; word-spacing: 0px; -webkit-text-stroke-width: 0px; text-decoration-thickness: initial; text-decoration-style: initial; text-decoration-color: initial;">• TUV CE, RoHS approved, &nbsp;Energy Efficiency Class of <span style="color: rgb(0, 0, 0); font-family: arial, helvetica, sans-serif; font-size: 14px; font-style: normal; font-variant-ligatures: normal; font-variant-caps: normal; font-weight: 400; letter-spacing: normal; orphans: 2; text-align: start; text-indent: 0px; text-transform: none; white-space: normal; widows: 2; word-spacing: 0px; -webkit-text-stroke-width: 0px; background-color: rgb(255, 255, 255); text-decoration-thickness: initial; text-decoration-style: initial; text-decoration-color: initial; display: inline !important; float: none;">E&nbsp; according to new ErP

<ul><li>Voltage(V): 220-240; 120-277</li><li>Certification: CE, ETL, EMC, FCC, GS, LVD, RoHS, SAA</li><li>Wattage(W): 15W 20W 30W 45W 60W 90W</li><li>Beam: 120°, 85*85°, 80°, 30*70° aisle, 55*90° wall washer, empty profile&nbsp;</li><li>Shade Direction: 30% up 70% down; 100% down</li><li>UGR: 16, 19, 22 depends on optics design</li><li>Dimmable: DALI-2, DALI DT8, ON/OFF, 1-10V, Zigbee 3.0</li><li>Continous Installaion: straight, L, T, and X.</li><li>CCT: 3000K, 4000K, Tunable White</li><li>Installaions: Suspendant, Surface, Track mounted</li><li>Product Length: 0.5, 1.2, 1.5, 1.8, 2.4 meter</li><li>Shade Type:Reflectors, MicroPrism, Opal diffusor</li><li>Body Colour: Black, White</li><li>Customized: Yes</li><li>Base Type: Plug &amp; Play Wago Connectors</li><li>Body Material: Aluminum</li><li>Warranty: 5 years</li><li>MOQ: 50</li></ul>

To power various indoor LED fixtures, the LEDGEAR® L1, L2 Junction Box Drivers have a silver finish with 1/2" NPT punched knockouts and features easy access cover panel. It is provided with leads and conduits opening for supply connection. Intended for contractor installations and is a NEMA 1 steel enclosure. There are Triac/ELV and 1-10V Dimmable option with constant current output from 3.6W to 40W.&nbsp;LEDGEAR L1 &amp; L2 driver provided with wire nuts(push-in wire connectors on request) for fast and easy wiring. Five 7/8" knockouts for maximum flexibility in positioning and in-line installation. And the driver case features side tabs with mounting screw holes to allow mounting of driver in under cabinet applications. steel box with dedicated compartment for hardwiring (120V, 277V).&nbsp;Application: US-standard LED panel light, troffer, downlight, and other indoor LED lighting applicationsSpecifications:<ul><li>Triac, ELV(110-120V input), 5 Modules covers 20 different current(120-1000mA) output @30-40V</li><li>1-10V(110-277V input), 5 Modules covers 20 different current(120-1000mA) output @28-40V</li></ul>

Turbo, a track light with flexible beam angle varies from 15° to 33°, delivering the flexible and dynamic lighting for targeted objects in different accent lighting situations. Comes with super high efficacy of 100lm/W for producing sufficient lighting, and provides 2in1 design for wattage adjustment between 32W &amp; 25W. Smooth beam angle changing with extremely uniform light, no dark spot or shadow.With adoption of advanced zoom technology, our adjustable track lamp is able to be manually adjusted by lens to produce the perfect lighting distribution and brightness. It offers a high flexibility of illuminating the objects in a diversified and effective manner.Besides, it's provided with 360 degree rotation and 90 degree tilt that allows for flexible pan/tilt locking for free positioning of light fittings and delivering ideal illumination of targeted objects.Applications: &nbsp;Retail shops, hotels, museums, restaurant, art galleries, showroom, and other commercial lighting like Fashion Stores, Shopping Malls, Supermarkets, Exhibitions, etc SpecificationsTurbo: 32W 3000-3300lm Dimmable, Zoomable 15° to 33°, Flicker Free

A premium track heads family provides super high quality of light with licker free, high efficacy and up to 95 CRI and super long lifespan over 100,000hrs.Solid and sleek cylinder appearance looks aesthetically eye-catching, the Hanz track head is an impressive modular track light system with interchangeable track head adaptors, which are compatible with H type, J type, J2 Type, L type and 2C2N)Tek) track systems. It can reduce the inventory and shorter the time to projects in the patented modular interface. Integrated with excellent diver, it’s compatible with most of the Triac and ELV dimmers. &nbsp;Also, it equipped with interchangeable CAMETA® TIR lens to offer multiple beam spreads interchange from 15 degrees to 60 degrees, also the black baffle help to get a visual comfortable light. 4 different wattage and lumen powered with the CREE CXB COB LED arrays, which makes more energy-saving with high CRI up to 95. Optimized thermal management leads a super long lifespan of 100000 hours, and five years warranty.Applications: Retail shops, hotels, museums, restaurant, art galleries, showroom, and other commercial lighting like Fashion Stores, Shopping Malls, Supermarkets, Exhibitions, etc.Specifications:<ul><li>TR-050-10: 10W, 780lm Ra90, 15°/38°/60°, Triac/ELV Dimming, Flicker Free</li><li>TR-051-15: 15W, 1400lm Ra90, 15°/24°/38°/60°, Triac/ELV Dimming, Flicker Free</li><li>TR-052-25: 25W, 2200lm Ra90, 15°/18°/24°/38°/60°, Triac/ELV Dimming, Flicker Free</li><li>TR-053-38: 38W, 3300lm Ra90, 24°/38°/60°, Triac/ELV Dimming, Flicker Free</li></ul>Features &amp; benefits<ul><li>H, J, J2(dual circuit), L, and Tek track system compatible options</li><li>Flicker Free</li><li>Dimmable with most of the triac dimmers and part of ELV dimmers</li><li>Smooth and linear dimming from 100% to 5%</li><li>THDi less than 18% @ without dimmer</li><li>Passive Powe Factor 0.98</li><li>Equipped with CREE CXB COB LED arrays</li><li>Interchangeable TIR Lens: 15, 24, 38 and 60</li><li>High CRI 90 and 82 for options</li><li>Full cutoff with regressed light source</li><li>Less than 3 SDCM MacAdam ellipse</li><li>&nbsp;Super long lifespan 100,000hrs @Ta=25°C</li><li>LED lifespan L70=100,000hrs,L90=35,000hrs @Ta=25°C</li><li>Over 30,000times ON/OFF cycle test</li></ul>

The LEDGEAR® &nbsp;Digital Universal Dimmer F92001-40028301 can be used with many common, dimmable, line voltage LED lamps, high voltage halogen and incandescent lamps, electronic transformers and Kinglumi Trailing tunable white(TTW®) LED lamps.The dimmer equipped with microcontroller and suitable for use in special applications where you need to dim off. Suitable for use in both commercial and residential lighting control in flush mounted(both screw and claws) that can control a maximum load of 400 W at 230 V.With safety to EN60669, EN55015 and providing protection from over temperature, short-circuit and overload, this is a high quality product that will give you reliable protection and service. Its standby power consumption is 0.5 W and EU EcoDesign compliant.The 4in1 universal dimming allowing to works with Resistive, Capacitive, Inductive and Kinglumi TTW® lamps. It helps to reduce the inventory.&nbsp; • &nbsp; Device works according to the leading edge, trailing edge phase control principle; also Kinglumi Trailing TW principle• &nbsp; &nbsp; Manual setting of the dimming principle suitable for the load• &nbsp; &nbsp; Allows extension push-button on dimming / switching• &nbsp; &nbsp; Dim to OFF with most LED light sources• &nbsp; &nbsp; Switch-on with last brightness or saved switch-on brightness• &nbsp; &nbsp; Switch-on brightness can be saved permanently• &nbsp; &nbsp; Suitable for both retrofit and new installations• &nbsp; &nbsp; Soft start* &nbsp;for customization(factory preset) only• &nbsp; &nbsp; Permissible AC cable 0.75-2.5mm² wire gauge• &nbsp; &nbsp; Built--in with permanent memory• &nbsp; &nbsp; 85°C Maximum case operation temperature(tc-point ¹)• &nbsp; &nbsp; Operating temperature ¹: -20°C ~ +45°C, the humidity: 20% ~ 85%• &nbsp; &nbsp; Five-year factory guarantee and lifetime technical support• &nbsp; &nbsp; Switching• &nbsp; &nbsp; Dimming• &nbsp; &nbsp; Colour temperature tuning* (only works with Kinglumi TTW® lamps)• &nbsp; &nbsp; Memory• &nbsp; &nbsp; Leading &amp; trailing selectableThe device provides the following protective functions:• &nbsp; &nbsp; Inrush current limitation through soft start• &nbsp; &nbsp; Electronic overload, over temperature protection• &nbsp; &nbsp; Electronic short-circuit protection• &nbsp; &nbsp; Integrated thermal fuse• &nbsp; &nbsp;Electronic over voltage More details, please refer to: http://www.kinglumi.com/product-1863.htmlUnboxing of dimmer: https://youtu.be/zUDx61SCw5cSUBSCRIBE to Kinglumi: https://www.youtube.com/channel/UCPY3y9WvRkeWiJOXYUgv2Pw

Designed as a family of architectural low profile recessed, trimless, surface and pendant mounted luminaires, available in 6 different aperture sizes(φ100, φ125, φ150, φ200, φ250, φ300). Milo is a high performance portfolio dedicated to architectural lighting segment. With complete modular design concept, the light engines, different reflectors and different installations, plus the DIP switches on both light engine and driver could have multiply of combination to satisfy diversified customer’s requirement.&nbsp;

Milo™ luminaire with aluminium heatsink and metal housing; no visible screws; surface powder coated in white housing, black heatsink; Vaccum aluminum plating PC reflector design with specular/high-gloss mirror, silver, black, gold, white option; workplace light suitable for VDUs according to DIN EN 12464-1 (UGR 19, UGR 22); high energy-efficient LEDs with very good colour rendering; binning initial ≤ 3 MacAdam; CRI ≥ 80; min. Over 70% of the luminous flux after 50,000 hours; degree of protection IP 54; optionally 1-10V, non-dimmable, DALI-2 &amp; Push-DIM, or Phase-cut dimmable; optionally with DALI DT8, Zigbee and Bluetooth.

Milo System on Youtube: https://youtu.be/nXipnJ5LpWg
Milo Details:&nbsp;http://kinglumi.com/product-1700.html

Specifications:
Installations: Recessed, Trimless, Surface, Pendant
Diamenter:&nbsp;Φ100 Φ125 Φ150 Φ165 Φ200 Φ250&nbsp;Φ300
Drivers: DALI-2 Push-DIM, 1-10V, Triac, ON/OFF, Zigbee, Bluetooth
Ajustable Current: each driver includes ~8 different current by dip switches.
Reflectors: Specular, Black, White, Gold, Silver
Tunable White: 2700-6500K available with DALI DT8, or bluetooth

1.Input Voltage：AC120~240V; 120-277, 220-240V
2.Power Factor：0.95
3.Luminaire efficiency：105lm/W
4.Color consistency SDCM：SDCM 3
5.Color Rendering：82, 90
6.Life Time：L80(B10)50,000H
7.UGR：19, 22
8.CCT：3000K/4000K/5000K; 3CCT in one
9.Protection Level：IP 54 in front
10.Storage Temperature：-40℃~+80 ℃
11.Working Temperature：-20℃~+40 ℃

The Smarter dimmable LED track light kits , which include black, silver and white finishes, provide a full line of perfect replacements for halogen track light fixtures. Due to their 120LM/W energy efficiency and advanced optics design, they offer desired quality lighting with great savings and long-life benefits of light fittings. Available in modular design with removable and interchangeable lighting components, there is a very easy access to customizable and diverse lighting solutions for such dimmable track lighting systems.Compatible with systems of 4 wire, 3 circuits, 2 wires, single circuit and one-phase, these 22W led track lighting kits can fit in with varieties of architectural layout. They are able to be used in plenty of applications such as retail stores, art galleries, residential areas, schools, museum, offices, hospitality and healthcare, etc. One of unique advantage for such best rated Smarter track lighting lies in its flexible installations covering track-mounted, pendant and ceiling mounted ways.&nbsp; Specifications:ONE engine with 5 installations4 size with 5 different packagesVarious accessories<ul><li>Lumens: 4800lm 3200lm 2600lm 1450lm 650lm</li><li>Interchangeable Beams: 12° 15° 24° 38° 60°</li><li>Dimmable: Triac/ELV(Phase-cut)</li><li>Ra: 95, 82</li><li>Cert: ETL, CB, CE, FCC, SAA</li><li>Power Factor：0.95</li><li>Luminaire efficiency：up to 125lm/W</li><li>Color consistency SDCM：SDCM 3</li><li>Color Rendering：82, 95</li><li>Storage Temperature：-40℃~+80 ℃</li><li>Working Temperature：-20℃~+40 ℃&nbsp;</li></ul> Accessories:Barndoor,snot, honeycomb, oval snoot, lens, colour filter/film Installation:<ol><li>Track spotlight, track suspension</li><li>Canopy spotlight, canopy suspension, canopy surface</li><li>Semi-recessed spotlight,Semi-recessed&nbsp;suspension, Semi-recessed&nbsp;surface</li></ol>Compatible Track Systems:<ul><li>4wires 3circuits from STAFF, EUTRAC, NORDIC, GLOBAL, NUCO, IVELA</li><li>J and J2 from Juno lighitng single and dual circuit</li><li>H from Halo lighitng</li><li>L from lightonlier</li><li>2C2N from Nordic Aluminum&nbsp;</li></ul>

The Xline LED linear fixture features contemporary, sleek and compact design, thoroughly blending with interior architectures to add value and distinction. Highly energy efficient with an outstanding efficacy performance of 110LM/W, &nbsp;these linear led track light fixtures are able to deliver adequate and uniform lighting for large commercial spaces where super bright lighting is required with significant energy savings.Compatible with 4-wire 3-circuit track system, such led linear light bar fixture can work together with LED track spot lights based on the same rail track. In places where general lighting, accent lighting and wall washer lighting are required, Xline modern linear track lights are the good choice for providing one-stop lighting solutions. They are available in a different lighting distribution patterns including Single /Double wall washer lighting: 25°x90°,Batwing distribution of 85°x85° and Lambertian: pattern of 120°.&nbsp;Features<ul><li>Input Voltage：AC120~240V</li><li>Power Factor：0.95</li><li>Lumens: 6000lm 3300lm</li><li>Luminaire efficiency：110lm/W</li><li>Beams: 25°x90°,Batwing 85°x85°, 30°x70°, Lambertian:120°</li><li>Color consistency SDCM：SDCM 3</li><li>Color Rendering：82, 95</li><li>Life Time：L80(B10)50,000H</li><li>CCT：3000K/4000K/5000K&nbsp;</li><li>Protection Level：IP 20</li><li>Storage Temperature：-40℃~+80 ℃</li><li>Working Temperature：-20℃~+45 ℃</li><li>Extrusion pure aluminum housingSleek and compact</li><li>Integrated on-site solutions light distributions</li><li>Ultraviolet (UV) + Infrared (IR) free light</li><li>Passive cooling system without fans</li></ul>ApplicationsResidential, Retail, Art-gallery, Museum, Automotive and Parking, Education, Government, Healthcare, Hospitality,Offices and Banks, etc.More details:&nbsp;http://kinglumi.com/product-1472.html

The Smarter™ range of Architectural cylinder pendant light is a versatile and high performance luminaire that offers precision lighting exactly as required. With sleek and classic style, this cylinder pendant light fixture can be used for any new construction, remodel, or retrofit lighting projects. It's created with modular Design, allowing for easy switch from track mounting to mono-point mounting, ideal for use in architectural, commercial, and residential applications.

The Smarter™ contemporary cylinder &nbsp;Pendant Lights adopt &nbsp;CREE®, Luminus® or Bridgelux® COB LED arrays, delivering 610 to 2600 lumens light output, with up to 120 lumen per watt. &nbsp;Available in black and white finishes, the fixture offers various power options including 8,10, 15 and 22 watts. In addition, it's supplied with interchangeable beam spreads of 15°,24°,38°,60°. The five-feet field-cuttable suspension cable makes it the perfect choice for installations of different heights.

1. Lumens: 4800lm 3200lm 2600lm 1450lm 650lm
2. Beams: 12°&nbsp;15° 24° 38° 60°
3. Dimmable: Triac/ELV(Phase-cut)
4. Ra: 95, 82
5. Cert: ETL, CB, CE, FCC, SAA
6.&nbsp;Power Factor：0.95
7.&nbsp;Luminaire efficiency：up to 125lm/W
8.&nbsp;Color consistency SDCM：SDCM 3
9.&nbsp;Color Rendering：82, 95
10.Storage Temperature：-40℃~+80 ℃
11.Working Temperature：-20℃~+40 ℃&nbsp;

More Details:&nbsp;http://kinglumi.com/product-1503.html

6000lm, 140lm/W, 3CCT &amp; 3Wattage in One, 120-277VMilo™ LED wallwash track light sets a new best-in-class performance benchmark for track wallwasher.It is designed for architectural vertical lighting, which delivers up to 6,000 lumens of beautiful, uniformly high quality light in multiple color temperatures and powers in just one fixture, making it an excellent choice for all possible applications.90°aiming horizontal; 360° vertical rotation allow to light where needed. All of this is combined with efficiency sure to turn heads – an incredible 140lm/W! 1.Input Voltage：AC120~277V2.Power Factor：0.953.Luminaire efficiency：up to 140lm/W4.Color consistency SDCM：SDCM 35.Color Rendering：82 956.Life Time：L80(B10)50,000H7.CCT：3000K-3500K-4000k(3in1)8.Power:&nbsp;50W-40W-30W, 38W-30W-22W(3in1, 2model)9. Flicker Free with Pst&lt;0.1%, SVM&lt;0.1, Ecodesign design complaint10.Protection Level：IP 20&nbsp;11.Storage Temperature：-40℃~+80 ℃12.Working Temperature：-20℃~+45 ℃&nbsp;13. Asymmetric Beam: 60°x90°

oStar,&nbsp;a 44mm cut-out tiny recessed downlight portfolios, includes adjustable and fixed version.It equipped with high brightness COB LED, and provides attractive lighting solutions for living areas, cloakroom, kitchens and bathrooms.&nbsp;Powered by phase-cut dimmable independent driver, very small in size, but provides 6pcs push-in connectors and pull relief, very easy for loop in and loop out.<table border="0" cellpadding="0" cellspacing="0" style="border-collapse: collapse;width:677pt;" width="901"><tbody><tr height="25" style="mso-height-source:userset;height:18.75pt;"><td height="25" style="height: 18.75pt; width: 133pt; text-align: center;" width="177">Product Code</td><td style="border-left: none; width: 136pt; text-align: center;" width="181">4.DL.132.A02</td><td style="border-left: none; width: 136pt; text-align: center;" width="181">4.DL.132.C02</td><td style="border-left: none; width: 136pt; text-align: center;" width="181">4.DL.133.A02</td><td style="border-left: none; width: 136pt; text-align: center;" width="181">4.DL.133.C02</td></tr><tr height="43" style="mso-height-source:userset;height:32.25pt;"><td height="43" style="height: 32.25pt; border-top: none; width: 133pt; text-align: center;" width="177">Product Name</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">oStar Downlight Fix Dimmable D44 200 Dim-to-warm</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">oStar Downlight Fix Dimmable D44 230</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">oStar Downlight Tilt Dimmable D44 200 Dim-to-warm</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">oStar Downlight Tilt Dimmable D44 230</td></tr><tr height="25" style="mso-height-source:userset;height:18.75pt;"><td height="25" style="height: 18.75pt; border-top: none; width: 133pt; text-align: center;" width="177">Input voltage</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">220-240V</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">220-240V</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">220-240V</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">220-240V</td></tr><tr height="25" style="mso-height-source:userset;height:18.75pt;"><td height="25" style="height: 18.75pt; border-top: none; width: 133pt; text-align: center;" width="177">Adjustable</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">Fix</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">Fix</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">Tilt</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">Tilt</td></tr><tr height="25" style="mso-height-source:userset;height:18.75pt;"><td height="25" style="height: 18.75pt; border-top: none; width: 133pt; text-align: center;" width="177">Max LED Power(W)</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">3.24</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">3.24</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">3.24</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">3.24</td></tr><tr height="25" style="mso-height-source:userset;height:18.75pt;"><td height="25" style="height: 18.75pt; border-top: none; width: 133pt; text-align: center;" width="177">Max. LED Current(mA)</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">180</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">180</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">180</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">180</td></tr><tr height="25" style="mso-height-source:userset;height:18.75pt;"><td height="25" style="height: 18.75pt; border-top: none; width: 133pt; text-align: center;" width="177">LED Voltage</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">18</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">18</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">18</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">18</td></tr><tr height="25" style="mso-height-source:userset;height:18.75pt;"><td height="25" style="height: 18.75pt; border-top: none; width: 133pt; text-align: center;" width="177">CRI Option</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">CRI 90</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">CRI 90</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">CRI 90</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">CRI 90</td></tr><tr height="25" style="mso-height-source:userset;height:18.75pt;"><td height="25" style="height: 18.75pt; border-top: none; width: 133pt; text-align: center;" width="177">Lumen Output</td><td style="border-top: none; border-left: none; text-align: center;">200lm</td><td style="border-top: none; border-left: none; text-align: center;">230lm</td><td style="border-top: none; border-left: none; text-align: center;">200lm</td><td style="border-top: none; border-left: none; text-align: center;">230lm</td></tr><tr height="25" style="mso-height-source:userset;height:18.75pt;"><td height="25" style="height: 18.75pt; border-top: none; width: 133pt; text-align: center;" width="177">Beam Angle</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">48°</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">48°</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">48°</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">48°</td></tr><tr height="25" style="mso-height-source:userset;height:18.75pt;"><td height="25" style="height: 18.75pt; border-top: none; width: 133pt; text-align: center;" width="177">Power factor</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">0.85</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">0.85</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">0.85</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">0.85</td></tr><tr height="25" style="mso-height-source:userset;height:18.75pt;"><td height="25" style="height: 18.75pt; border-top: none; width: 133pt; text-align: center;" width="177">External Dimmable Driver</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">Phase-cut</td><td style="border-top: none; width: 136pt; text-align: center;" width="181">Phase-cut</td><td style="border-top: none; width: 136pt; text-align: center;" width="181">Phase-cut</td><td style="border-top: none; width: 136pt; text-align: center;" width="181">Phase-cut</td></tr><tr height="25" style="mso-height-source:userset;height:18.75pt;"><td height="25" style="height: 18.75pt; border-top: none; width: 133pt; text-align: center;" width="177">CCT Option</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">Dim-to-Warm 2000-2700K</td><td style="border-top: none; width: 136pt; text-align: center;" width="181">2700K,300K,4000K</td><td style="border-top: none; width: 136pt; text-align: center;" width="181">Dim-to-Warm 2000-2700K</td><td style="border-top: none; width: 136pt; text-align: center;" width="181">2700K,300K,4000K</td></tr><tr height="25" style="mso-height-source:userset;height:18.75pt;"><td height="25" style="height: 18.75pt; border-top: none; width: 133pt; text-align: center;" width="177">Dimension(mm)</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">D50*H38</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">D50*H38</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">D50*H33</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">D50*H33</td></tr><tr height="25" style="mso-height-source:userset;height:18.75pt;"><td height="25" style="height: 18.75pt; border-top: none; width: 133pt; text-align: center;" width="177">Cut-out(mm)</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">44</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">44</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">44</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">44</td></tr><tr height="25" style="mso-height-source:userset;height:18.75pt;"><td height="25" style="height: 18.75pt; border-top: none; width: 133pt; text-align: center;" width="177">Suitable for Ceiling Thickness</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">1-15mm</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">1-15mm</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">1-15mm</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">1-15mm</td></tr><tr height="25" style="mso-height-source:userset;height:18.75pt;"><td height="25" style="height: 18.75pt; border-top: none; width: 133pt; text-align: center;" width="177">UGR</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">12</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">12</td><td style="border-top: none; border-left: none; text-align: center;">12</td><td style="border-top: none; border-left: none; text-align: center;">12</td></tr><tr height="25" style="mso-height-source:userset;height:18.75pt;"><td height="25" style="height: 18.75pt; border-top: none; width: 133pt; text-align: center;" width="177">Air-tight</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">Yes</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">Yes</td><td style="border-top: none; border-left: none; text-align: center;">No</td><td style="border-top: none; border-left: none; text-align: center;">No</td></tr><tr height="25" style="mso-height-source:userset;height:18.75pt;"><td height="25" style="height: 18.75pt; border-top: none; width: 133pt; text-align: center;" width="177">Electrical Connection</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">Push-fit looping terminals</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">Push-fit looping terminals</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">Push-fit looping terminals</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">Push-fit looping terminals</td></tr><tr height="25" style="mso-height-source:userset;height:18.75pt;"><td height="25" style="height: 18.75pt; border-top: none; width: 133pt; text-align: center;" width="177">Finish</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">Black, White</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">Black, White</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">Black, White</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">Black, White</td></tr><tr height="25" style="mso-height-source:userset;height:18.75pt;"><td height="25" style="height: 18.75pt; border-top: none; width: 133pt; text-align: center;" width="177">Quick installation</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">loop in and loop out system</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">loop in and loop out system</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">loop in and loop out system</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">loop in and loop out system</td></tr><tr height="25" style="mso-height-source:userset;height:18.75pt;"><td height="25" style="height: 18.75pt; border-top: none; width: 133pt; text-align: center;" width="177">Material</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">Die casting aluminum</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">Die casting aluminum</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">Die casting aluminum</td><td style="border-top: none; border-left: none; width: 136pt; text-align: center;" width="181">Die casting aluminum</td></tr></tbody></table> Features &amp; Benefits <ul><li>Input Voltage: AC 220V-240V, 50/60Hz</li><li>Cut-out: 44mm</li><li>Comfort and soft light output, UGR&lt;12</li><li>Quick installation, loop in and loop out system</li><li>Die casting aluminum housing</li><li>Dim to warm available</li><li>Macadam 3 SDCM</li><li>Bridgelux &amp; Cree chips</li><li>Certification: CE &amp; ROSH</li><li>IP44 with the functions of dust-proof, water-proof</li></ul>

Originate from last generation, Xline™ plus is aesthetic and minimalist, easier for installations and newly developed the surface and track mounted besides the pendant. It’s flexible and seamless continuous connection to build creative and innovative lighting system.Distinctively rectangular aluminum luminaire housing from extruded aluminum profile; No visible screws; Indirect output reflected from the ceiling provide a softer and ambient illumination. The vaccum aluminum plating faceted louver with lens design minimized the glare. Suitable for VDUs workplace light according to EN 12464-1 (UGR 19, UGR 22); Available in 1167mm and 2330mm of length, with DALI, 0-10V or ON/OFF dimming control. Various lighting distributions meet the requirement of generation lighting, asymmetric distribution for shelves and wallwasher, bi-symmetric distribution for aisle lighting.
