12040 Industrial Ventilation Equipment Refrigerator Centrifugal Frameless Cooling Fan

DC Ventilation Equipment Cross Flow Cooling Fan

Industrial 220V-240V Metal Axial Cooling Brushless Air Cooler Exhaust Fan

DC Brushless Motor 5V/12V/24V Cooling Axial Ventilation Exhaust Fan 92X92X25mm

China Supplier DC Brushless Axial Cooling Fan for Freezer 120X120X25mm

Electric Brushless Aluminum Housing 120X120X38mm Axial Freezer AC Cooling Fan

DC Brushless Centrifugal Exhaust Fan Small Air Blower

DC Brushless Motor 5V/12V/24V Exhaust Cooling Turbine Centrifugal Blower Fan

5V/12V/24V DC Brushless Axial Cooling Exhaust Fan for Ventilator 80X80X25mm

<ul>
	<li>Rated voltage: DC 5V, 12V, 24V, 48V.</li>
	<li>It have various of sizes ranging from:25*25*07mm to172*172*51mm.</li>
	<li>Type: ball bearing, sleeve bearing.</li>
	<li>Safety approvals: CE, TUV, UL, CUL, CCC.</li>
	<li>Electric strength: 1mA max. at 1000V AC for 1 min between lead wire and frame.</li>
	<li>Insulation resistance: 10M ohm between lead wire and frame (DC 500V).</li>
	<li>Life expectancy (ball bearing): 50,000h rain at 25 degree C, relative humidity: 65%+/-20%.</li>
	<li>Life expectancy (sleeve bearing): ＞30,000h rain at 25 degree C, relative humidity: 65%+/-20%.</li>
	<li>Operation temperature: -10 to 70℃.</li>
	<li>Storage temperature: -40 to 75℃.</li>
	<li>Lead wire: UL1007 (AWG18-30).</li>
	<li>Protection: motor protection and polarity protection.</li>
	<li>Plastic material: black PBT (UL 94v-0) glass filled.</li>
	<li>Frame: plastic, impeller: plastic.</li>
	<li>Function: function type is optional.</li>
</ul>

<ul>
	<li>Size: 2,507-17,251</li>
	<li>Voltage: 5/12/24V</li>
</ul>

<ul>
	<li>Size: 30,090-60,300</li>
	<li>Voltage: 12/24/110/220/240V</li>
</ul>

<ul>
	<li>Size: from 51 x 20 x 15mm - 120 x 60 x 32mm</li>
	<li>Voltage: 5V/12V/24V</li>
	<li>Speed: 2,000rpm-5,500rpm</li>
</ul>

This crossflow fan is made of quality materials for a long service life. It is professionally engineered to deliver high performance. This crossflow fan is designed with the ball bearings and sleeve bearings.
<ul>
	<li>DC/AC crossflow fans have the reverse polarity protection.</li>
	<li>Impeller’s diameter ranging from 30mm to 60mm.</li>
	<li>Impeller’s length ranging from 90mm to 300mm.</li>
	<li>It can run on the 5V, 12V, 24V or 48V DC.</li>
	<li>Special size and voltage could be customized.</li>
	<li>Meet the worldwide safety requirements.</li>
	<li>Certificate: UL/CUL/CE/SGS/REACH.</li>
</ul>

<ul>
	<li>Model number:HT-A4808,HT-A4815,HT-A4820</li>
	<li>Voltage:100～380v</li>
	<li>Frequency:50/60HZ</li>
	<li>Operation temperature:-10～70℃</li>
	<li>Shaft length and shape,Rated current, Input power,Rated Speed:according to customers' requirement</li>
	<li>Thickness:8～30mm</li>
	<li>Shaft diameter:3.0～5.0mm</li>
	<li>Lead wire（Optional）:AWG22 UL1015</li>
</ul>

HTD9225:
<ul>
	<li>Frame size: 92 x 92 x 25mm/92*92*38mm</li>
	<li>Voltage: 5V/12V/24V</li>
	<li>Bearing type: sleeve bearing/ball bearing</li>
	<li>Speed: 1200RPM-3800RPM</li>
	<li>Safety approvals: CE, TUV, UL, CUL, ROHS</li>
	<li>Electric strength: 1m Amax at 1000VAC for 1 min between lead wire and frame.</li>
	<li>Insulation resistance: 10M ohm between lead wire and frame (DC 500V)</li>
	<li>Life expectancy (ball bearing): 50,000hrs rain at 25 degree C relative humidity 65% +/-20%</li>
	<li>Life expectancy (sleeve bearing): ＞30,000hrs rain at 25 degree C relative humidity 65% +/-20%</li>
	<li>Operation temperature: -10 to 70℃</li>
	<li>Storage temperature: -40 to 75℃</li>
	<li>Lead wire: UL1007 (AWG18-30)</li>
	<li>Protection: motor protection and polarity protection</li>
	<li>Plastic material: black PBT (UL 94v-0) glass filled</li>
</ul>

<ul>
	<li>Rated voltage: 12V/24V DC.</li>
	<li>Type: ball bearing, sleeve bearing.</li>
	<li>Safety approvals: CE, TUV, UL, CUL, CCC.</li>
	<li>Electric strength: 1mA max. at 1000V AC for 1 min between lead wire and frame.</li>
	<li>Insulation resistance: 10M ohm between lead wire and frame (DC 500V).</li>
	<li>Life expectancy (ball bearing): 50,000h rain at 25 degree C, relative humidity: 65%+/-20%.</li>
	<li>Life expectancy (sleeve bearing): ＞30,000h rain at 25 degree C, relative humidity: 65%+/-20%.</li>
	<li>Operation temperature: -10 to 70℃.</li>
	<li>Storage temperature: -40 to 75℃.</li>
	<li>Lead wire: UL1007 (AWG18-30).</li>
	<li>Protection: motor protection and polarity protection.</li>
	<li>Plastic material: black PBT (UL 94v-0) glass filled.</li>
	<li>Frame: plastic, impeller: plastic.</li>
	<li>Function: function type is optional.</li>
</ul>
