產品規格
尺寸
292mm*194mm*202mm
重量
≈6.5 KG
Certification
CE、FCC、ROHS、PSE+METI、UL2743report、UN38.3、MSDS
是否可訂造
可以
AC output standard including
EU / US / JP / CN/ AU, customized versions in other countries and regions
電池類型
鋰金屬電池
型號編號
MP500
產品簡介
| Model | MP500 | |
| AC output standard including | EU / US / JP / CN/ AU, customized versions in other countries and regions | |
| Certification | CE、FCC、ROHS、PSE+METI、UL2743report、UN38.3、MSDS | |
| Product size | 292mm*194mm*202mm | |
| Product weight | ≈6.5 KG | |
| Battery | Battery material | Ternary lithium 18650,3.7V 140400mAh |
| Battery capacity | 519.4Wh | |
| Battery life | ≥ 800 Cycle (70%) | |
| AC output | Rated power | 500W |
| Output voltage | 230V 50hz | |
| Output waveform | Pure sine wave | |
| UPS（10ms） | NO | |
| Overload / short circuit protection | YES | |
| Parallel operation | NO | |
| DC output | USB-A | QC3.0 3*18W 5V 2.5A |
| Type-C (fast charging) | PD Fast charging 1*60W:5V/9V/12V/15/20V 3A | |
| Wireless charging | 1*10W | |
| DC output | 5525*2 +The cigarette lighter(14V/8A) | |
| Charge | AC charging power | 100W |
| Solar charging | 12-26V/6A | |
| Input overvoltage protection | YES | |
| Car charging | YES | |
| Charging time | 6-7h | |
| Work efficiency (Conversion rate) | Inverter ≥ 85% board end efficiency | |
| Drop test | YES | |
| Product material | ABS+PC | |
| Battery replacement | NO | |
| Specification | NO | |
| LED intelligent display screen | ||
| Built in double strong LED light, supporting SOS flash | ||
| External power transformer | ||
| *Input undervoltage, output overvoltage, output undervoltage, overload, short circuit, over temperature, over current, BMS management adopts secondary protection | ||
| "Working environment temperature -10 ℃ - 40 ℃, Charging temperature 0 ℃ - 40 ℃, | ||
