The global certified BLK Series is a non-isolated high efficiency smart LED driver. 6kV surge protection level, 100khour long life and 5-year warranty provide high confidence to luminaire users. It supports not only traditional 4-in-1 control, but also DALI2.0 and other protocols. NFC and cable programming are both available for users. All around protections including digital OTP (internal and external by NTC) with auto-recovery secure 24hour non-stop operation for luminaires.&nbsp;

The global certified BLD Series is an extremely high efficiency smart LED driver for grow lights. 100khour long life and 7-year warranty provide high confidence to luminaire users. NFC and cable programming are both available for users. All around protections including digital OTP (internal and external by NTC) with auto-recovery secure non-stop operation for luminaires. Customized active daisy chain, master mode and button design greatly ease the design for horticultural usage.&nbsp;

The global certified SLK Series is a non-isolated extremely wide input smart LED driver. 10kV surge protection level, 100khour long life and 5-year warranty provide high confidence to luminaire users. It supports not only traditional 4-in-1 control, but also DALI2.0 and other protocols. NFC and cable programming are both available. All around protections including digital OTP (internal and external by NTC) with auto-recovery secure 24hour non-stop operation for luminaires.&nbsp;

The global certified APD Series is a dual stage high efficiency smart LED driver. 10kV surge protection level, 100khour long life and 7-year warranty provide high confidence to luminaire users. It supports not only traditional 0-10V control, but also D4i smart protocols with NFC programmability. All around protections including digital OTP (internal and external by NTC) with auto-recovery secure 24hour non-stop operation for luminaires.

The global certified TLD Series is a dual stage extremely wide input smart LED driver. 10kV surge protection level, 100khour long life and 7-year warranty provide high confidence to luminaire users. It supports not only traditional 4-in-1 control, but also DALI2.0 and other protocols. NFC and cable programming are both available for users. All around protections including digital OTP (internal and external by NTC) with auto-recovery secure 24hour non-stop operation for luminaires.&nbsp;

<span style="color: rgb(19, 19, 19); font-family: Roboto, Arial, sans-serif; font-size: 14px; font-style: normal; font-variant-ligatures: normal; font-variant-caps: normal; font-weight: 400; letter-spacing: normal; orphans: 2; text-align: start; text-indent: 0px; text-transform: none; widows: 2; word-spacing: 0px; -webkit-text-stroke-width: 0px; white-space: pre-wrap; background-color: rgba(0, 0, 0, 0.05); text-decoration-thickness: initial; text-decoration-style: initial; text-decoration-color: initial; display: inline !important; float: none;">The TYKx series by uPowerTek is a range of high-performance multi-channel RGBW LED drivers designed for sports lighting. These drivers offer output power from 600W to 2000W with support for DMX, DALI, and other dimming protocols. Key features include high efficiency (up to 97%), low inrush current, robust surge protection (20kV), and fast dimming capabilities. They support remote installations, minimizing voltage drop over long distances. The drivers are built for durability with IP66 and IK08 ratings, making them ideal for demanding environments.&nbsp;

Features:

<ul>
	<li>Supply Voltage: 90-305Vac or 127-420Vdc, 380Vac for 2 hours</li>
	<li>Great Surge Immunity 10kV</li>
	<li>PWM Output Frequency &gt;1kHz</li>
	<li>100,000Hour Life @ Tc=75℃</li>
	<li>5 Year Warranty @ Tc&lt;=75℃</li>
	<li>0-10V/PWM/DALI /Push (Switch) /DMX (RDM) Dimmable</li>
	<li>2% Minimum Dimming Output</li>
	<li>Dim Off with 0.5W Standby</li>
	<li>12V 300mA Auxiliary Power to Power Controllers and Fans (Optional)</li>
	<li>Input Over Voltage Protection (Optional)</li>
	<li>Class II Model Available</li>
	<li>UL Class P, ENEC/CB/CCC SELV Output</li>
	<li>Safety according to EN 61347-1, 61347-2-3, 61347-2-13, 62384</li>
</ul>
Technical Data:

<ul>
	<li>Input Voltage: 90～305Vac&nbsp;or 127V-420Vdc, 380Vac for 2 hours</li>
	<li>Input Frequency: 47～63Hz</li>
	<li>Power Factor: &gt;0.9@60-100%load, refer to PF vs. Load curve</li>
	<li>THD: &lt;15%@60-100%load, refer to THD vs. Load curve</li>
	<li>Input Current: 0.95Amax@120Vac &amp; Full-Load, 0.48Amax@220Vac &amp; Full-Load</li>
	<li>Inrush Current: 65A peak, 1.2ms duration, &lt;0.25A2s@230Vac, Cold Start; 70A peak, 1.3ms duration, &lt;0. 5A2s@277Vac, Cold Start</li>
	<li>Leakage Current: 1mA&nbsp;max @277Vac 60Hz, UL8750,0.75mAmax @220Vac 50Hz, IEC61347-1</li>
	<li>Input Under Voltage: Shut down&nbsp;and auto-restart</li>
	<li>Input Over Voltage: *Optional: Shutdown @320Vac</li>
	<li>Surge Protection: Line to line 6kV, line to ground 10kV, IEC 61000-4-5</li>
	<li>Voltage Accuracy: ±3%Vo</li>
	<li>Setup Time: 1.2s max.</li>
	<li>Overshoot: 10%&nbsp;Vo, max.</li>
	<li>Output Over&nbsp;Current: 120% Io, typ.</li>
	<li>Short Circuit: Auto recovery. The output recovers when short is removed.</li>
	<li>Over Temperature: Turn off the output when Tc≧105±10℃; Auto Recovery When Tc≦70±10℃</li>
	<li>Operating Temperature: -40℃～+70℃&nbsp;；10%RH～100%RH &nbsp;</li>
	<li>Storage Temperature: -40℃～+85℃；&nbsp;5%RH～100%RH</li>
	<li>MTBF: ≥320,000 hours, 75℃&nbsp;case &nbsp;temperature (MIL-HDBK-217F)</li>
	<li>Lifetime; ≥100,000 hours, 75℃&nbsp;case &nbsp;temperature, refer to life vs. Tc curve</li>
	<li>Case Temperature: 90℃&nbsp;max, marked in the Tc point of label</li>
	<li>Dimensions: 6.34x2.66x1.32&nbsp;by inch&nbsp;(body), &nbsp;&nbsp;7.40x2.66x1.32&nbsp;by inch&nbsp;(endcaps included); 161.0x67.5x33.5&nbsp;by mm (body), 188.0x67.5x33.5&nbsp;by mm (endcaps included)</li>
	<li>Net Weight: 800g</li>
	<li>Packing: 25pcs, 21kg per carton, carton size: 490x370x230mm</li>
</ul>
Notes:&nbsp;&nbsp;Unless specified, all the test results are measured in 25℃&nbsp;room temperature.&nbsp;
&nbsp;

<ul>
	<li>UL Certified IP67 Waterproof 150W Constant Current LED Driver</li>
	<li>Great Surge Immunity 10kV</li>
	<li>NFC Programmability</li>
	<li>-55℃Cold Ambient Startup</li>
	<li>12V 300mA Auxiliary Power</li>
	<li>Dim Off with 0.5W Standby Power</li>
	<li>UL Class P</li>
	<li>7 Year Warranty</li>
	<li>+/-2% Output Current Accuracy</li>
</ul>

Features:

<ul>
	<li>Supply Voltage:&nbsp;180-528Vac or 250-740Vdc</li>
	<li>Great Surge Immunity 10kV</li>
	<li>100,000Hour Life @ Tc=75℃&nbsp;</li>
	<li>7&nbsp;Year Warranty @ Tc&lt;=75℃&nbsp;</li>
	<li>AirsetTM&nbsp;NFC Programmability</li>
	<li>+/-2% Output Current Accuracy (Programmable Model)</li>
	<li>0-10V/PWM/Time/DALI&nbsp;/DMX&nbsp;(Optional) Dimmable</li>
	<li>Dim Off with&nbsp;1.5W Standby Power</li>
	<li>12V 300mA Auxiliary Power to Power Controllers and Fans (Optional)</li>
	<li>UL Class P, ENEC/CB/CCC SELV Output</li>
	<li>Safety according to EN 61347-1, 61347-2-3,61347-2-13, 62384</li>
</ul>
Technical Data :

<ul>
	<li>Input Voltage: 180-528Vac or 250-740Vdc</li>
	<li>Input Frequency: 47～63Hz</li>
	<li>Power Factor: &gt;0.9@60-100%load, refer to PF vs. Load curve</li>
	<li>THD: &lt;15%@60-100%load, refer to THD vs. Load curve</li>
	<li>Input Current: 1.8 Amax@277Vac &amp; Full-Load, 0.9Amax@480Vac &amp; Full-Load</li>
	<li>Inrush Current: 65A peak, 1.2ms duration@277Vac ,&nbsp;&lt;0.25A2s&nbsp;</li>
	<li>70A peak, 1.3ms duration@480Vac ,&nbsp;&lt;0.5A2s</li>
	<li>Leakage Current: 1mA&nbsp;max @277Vac 60Hz, UL8750,0.75mAmax @380Vac 50Hz, IEC61347-1</li>
	<li>Input Under Voltage: Shut down&nbsp;and auto-restart</li>
	<li>Surge Protection: Line to line 6kV, line to ground 10kV, IEC 61000-4-5</li>
	<li>Current Accuracy: ±5%Io</li>
	<li>Ripple Current: Ip-p:5%Io max</li>
	<li>Setup Time: 1.2s max</li>
	<li>Overshoot: 10%&nbsp;Io max &amp; LED Load</li>
	<li>Output Over Voltage: 120% Vomax, typ.</li>
	<li>Short Circuit: Auto recovery. The output recovers when short is removed.</li>
	<li>Over Temperature: Lower the output current when Tc≧105±10℃; Auto Recovery When Tc≦70±10℃</li>
	<li>Auxiliary&nbsp;Power (Vaux)&nbsp; : 12V+/-5%, 300mA max</li>
	<li>Operating Temperature: -40℃～+70℃&nbsp;；10%RH～100%RH</li>
	<li>Storage Temperature: -40℃～+85℃；&nbsp;5%RH～100%RH</li>
	<li>MTBF: ≥280,000 hours, 75℃&nbsp;case &nbsp;temperature (MIL-HDBK-217F)</li>
	<li>Lifetime: ≥100,000 hours, 75℃&nbsp;case &nbsp;temperature, refer to life vs. Tc curve</li>
	<li>Case Temperature: 90℃&nbsp;max, marked in the Tc point of label</li>
	<li>Dimensions: 9.44x3.54x1.63 by inch (body), &nbsp;10.51x3.54x1.63 by inch&nbsp;(endcaps included); 240 x 90 x 41.5&nbsp;by mm (body), &nbsp;&nbsp;267 x 90 x 41.5&nbsp;by mm (endcaps included)</li>
	<li>Net Weight: 1650g</li>
	<li>Packing: 10pcs/Carton/19.2kg, 490x370x345 by mm</li>
</ul>
Notes:&nbsp;&nbsp;Unless specified, all the test results are measured in 25℃&nbsp;room temperature.
&nbsp;* marked items&nbsp;are optional and contact with sales people to get the functions.
&nbsp;

Features:

<ul>
	<li>Supply Voltage: 90-305Vac or 127-420Vdc</li>
	<li>Great Surge Immunity 10kV</li>
	<li>-55℃Cold Ambient Startup (Optional)</li>
	<li>100,000Hour Life @ Tc=75℃</li>
	<li>7 Year Warranty @ Tc&lt;=75℃</li>
	<li>0-10V/PWM/Time/DALI/DMX (RDM) Dimmable</li>
	<li>Dim Off with 0.5W Standby Power &nbsp;&nbsp;</li>
	<li>12V 300mA Auxiliary Power to Power&nbsp;Controllers and Fans (Model Depending)</li>
	<li>Class II Model Available</li>
	<li>UL Class P, Class 2</li>
	<li>SELV Output, safety according to EN 61347-1, 61347-2-3, 61347-2-13, 62384</li>
</ul>
Technical Data :

<ul>
	<li>Input Voltage: 90～305Vac&nbsp;or 127V-420Vdc</li>
	<li>Input Frequency: 47～63Hz</li>
	<li>Power Factor: &gt;0.9@60-100%load, refer to PF vs. Load curve</li>
	<li>THD: &lt;15%@60-100%load, refer to THD vs. Load curve</li>
	<li>Input Current: 0.8Amax@120Vac &amp; Full-Load, 0.4Amax@220Vac &amp; Full-Load</li>
	<li>Inrush Current: 65A peak, 1.2ms duration, &lt;0.25A2s@230Vac, Cold Start; 70A peak, 1.3ms duration, &lt;0. 5A2s@277Vac, Cold Start</li>
	<li>Leakage Current: 1mA&nbsp;max @277Vac 60Hz, UL8750,0.75mAmax @220Vac 50Hz, IEC61347-1</li>
	<li>Input Under Voltage: Shut down&nbsp;and auto-restart</li>
	<li>Input Over Voltage: *Optional: Shutdown @320Vac</li>
	<li>Surge Protection: Line to line 6kV, line to ground 10kV, IEC 61000-4-5</li>
	<li>Current Accuracy: ±5%Io</li>
	<li>Ripple Current: Ip-p:5%Io max</li>
	<li>Setup Time: 1.2s max</li>
	<li>Overshoot: 10%&nbsp;Io max &amp; LED Load</li>
	<li>Output Over Voltage: 120% Vomax, typ.</li>
	<li>Short Circuit: Auto recovery. The output recovers when short is removed</li>
	<li>Over Temperature: Lower the output current when Tc≧105±10℃; Auto recovery when Tc≦70±10℃</li>
	<li>Auxiliary&nbsp;Power (Vaux)&nbsp; : 12V+/-5%, 300mA max</li>
	<li>Operating Temperature: -40℃～+70℃&nbsp;；10%RH～100%RH &nbsp;</li>
	<li>Storage Temperature: -40℃～+85℃；&nbsp;5%RH～100%RH</li>
	<li>MTBF: ≥320,000 hours, 75℃&nbsp;case &nbsp;temperature (MIL-HDBK-217F)</li>
	<li>Lifetime: ≥100,000 hours, 75℃&nbsp;case &nbsp;temperature, refer to life vs. Tc curve</li>
	<li>Case Temperature: 90℃&nbsp;max, marked in the Tc point of label</li>
	<li>Dimensions: 10.72x1.41x1.18&nbsp;by inch&nbsp;(body), &nbsp;&nbsp;11.33x1.41x1.18&nbsp;by inch&nbsp;(endcaps included); 272.4x36x30&nbsp;by mm (body), 288.0x36x30&nbsp;by mm (endcaps included)</li>
	<li>Net Weight: 650g</li>
	<li>Packing: TBD</li>
</ul>
Notes:&nbsp;&nbsp;Unless specified, all the test results are measured in 25℃&nbsp;room temperature.
* marked items&nbsp;are optional and contact with sales people to get the functions.
&nbsp;

Features:

<ul>
	<li>Supply Voltage: 90-305Vac or 127-420Vdc, 380Vac for 2 hours</li>
	<li>Great Surge Immunity 10kV</li>
	<li>55℃Cold Ambient Startup (Optional)</li>
	<li>100,000Hour Life @ Tc=75℃</li>
	<li>7 Year Warranty @ Tc&lt;=75℃</li>
	<li>AirsetTM NFC Programmability</li>
	<li>+/-2% Output Current Accuracy (Programmable Model)</li>
	<li>0-10V/PWM/Time/DALI /DMX (Optional) Dimmable</li>
	<li>Dim Off with 0.5W Standby Power</li>
	<li>12V 300mA Auxiliary Power to Power Controllers and Fans (Optional)</li>
	<li>Input Over Voltage Protection (Optional)</li>
	<li>UL Class P, ENEC/CB/CCC SELV Output</li>
	<li>Safety according to EN 61347-1, 61347-2-3,61347-2-13, 62384</li>
</ul>
Technical Data :

<ul>
	<li>Input Voltage: 90～305Vac&nbsp;or 127V-420Vdc, 380Vac for 2 hours</li>
	<li>Input Frequency: 47～63Hz</li>
	<li>Power Factor: &gt;0.95@60-100%load, refer to PF vs. Load curve</li>
	<li>THD: &lt;15%@60-100%load, refer to THD vs. Load curve</li>
	<li>Input Current: 3.6Amax@120Vac &amp; Full-Load, 2.0Amax@220Vac &amp; Full-Load</li>
	<li>Inrush Current: 65A peak, 1.2ms duration, &lt;0.25A2s@230Vac, Cold Start; 70A peak, 1.3ms duration, &lt;0. 5A2s@277Vac, Cold Start</li>
	<li>Leakage Current: 1mA&nbsp;max @277Vac 60Hz, UL8750,0.75mAmax @220Vac 50Hz, IEC61347-1</li>
	<li>Input Under Voltage: Shut down&nbsp;and auto-restart</li>
	<li>Input Over Voltage: *Optional: Shutdown @320Vac</li>
	<li>Surge Protection: Line to line 6kV, line to ground 10kV, IEC 61000-4-5</li>
	<li>Current Accuracy: ±5%Io</li>
	<li>Ripple Current: Ip-p:5%Io max</li>
	<li>Setup Time: 1.2s max</li>
	<li>Overshoot: 10%&nbsp;Io max &amp; LED Load</li>
	<li>Output Over Voltage: 120% Vomax, typ.</li>
	<li>Short Circuit: Auto recovery. The output recovers when short is removed.</li>
	<li>Over Temperature: Lower the output current when Tc≧105±10℃; Auto Recovery When Tc≦70±10℃</li>
	<li>Auxiliary&nbsp;Power (Vaux)&nbsp; : 12V+/-5%, 300mA max</li>
	<li>Operating Temperature: -40℃～+70℃&nbsp;；10%RH～100%RH</li>
	<li>Storage Temperature: -40℃～+85℃；&nbsp;5%RH～100%RH</li>
	<li>MTBF: ≥280,000 hours, 75℃&nbsp;case &nbsp;temperature (MIL-HDBK-217F)</li>
	<li>Lifetime: ≥100,000 hours, 75℃&nbsp;case &nbsp;temperature, refer to life vs. Tc curve</li>
	<li>Case Temperature: 90℃&nbsp;max, marked in the Tc point of label</li>
	<li>Dimensions: 8.82x3.54x1.63 by inch (body), &nbsp;9.88x3.54x1.63 by inch&nbsp;(endcaps included); 224&nbsp;x 90 x 41.5&nbsp;by mm (body), &nbsp;&nbsp;251 x 90 x 41.5&nbsp;by mm (endcaps included)</li>
	<li>Net Weight: 1600g</li>
	<li>Packing: 12pcs/Carton/21.3kg, 490 x 370 x 345 by mm</li>
</ul>
Notes:&nbsp;&nbsp;Unless specified, all the test results are measured in 25℃&nbsp;room temperature.
* marked items&nbsp;are optional and contact with sales people to get the functions.
&nbsp;

Features:

<ul>
	<li>Supply Voltage: 90-305Vac or 127-250Vdc</li>
	<li>100,000Hour Life @ Tc=75C</li>
	<li>5 Year Warranty</li>
	<li>AirsetTM&nbsp;NFC Programmability</li>
	<li>1% 0-10V/PWM/Time/DALI Dimmable</li>
	<li>Isolated Dimming Input</li>
	<li>Dim Off with 0.5W Standby Power (Optional)</li>
	<li>12V 300mA Auxiliary Power (Optional)</li>
	<li>Low Inrush Current</li>
	<li>Class II (Optional)</li>
	<li>UL Type TL, Class 2</li>
	<li>ENEC/CB/CCC SELV Output</li>
	<li>Safety according to EN 61347-1, 61347-2-3,&nbsp;61347-2-13, 62384</li>
</ul>
Technical Data :

<ul>
	<li>Input Voltage: 90～305Vac&nbsp;or 127V-250Vdc</li>
	<li>Input Frequency: 47～63Hz</li>
	<li>Power Factor: &gt;0.9@60-100%load, refer to PF vs. Load curve</li>
	<li>THD: &lt;15%@60-100%load, refer to THD vs. Load curve</li>
	<li>Input Current: 1.8 Amax@110Vac &amp; Full-Load, 0.9Amax@220Vac &amp; Full-Load</li>
	<li>Inrush Current: 2A peak, 1.2ms duration, &lt;0.025A2s@230Vac, Cold Start; 4A peak, 1.3ms duration, &lt;0. 05A2s@277Vac, Cold Start</li>
	<li>Leakage Current: 1mA&nbsp;max @277Vac 60Hz, UL8750, 0.75mAmax @220Vac 50Hz, IEC61347-1</li>
	<li>Input Under Voltage: Shut down&nbsp;and auto-recovery</li>
	<li>Surge Protection: Line to line 4kV, line to ground 6kV, IEC 61000-4-5</li>
	<li>Current Accuracy: ±5%Io</li>
	<li>Ripple Current: Ip-p:5%Io max</li>
	<li>Setup Time: 1.2s max</li>
	<li>Overshoot: 10%&nbsp;Io max &amp; LED Load</li>
	<li>Output Over Voltage: 120% Vomax, typ.</li>
	<li>Short Circuit: Auto recovery. The output recovers when short is removed.</li>
	<li>Over Temperature: Lower the output current when Tc≧105±10℃; Auto Recovery When Tc≦70±10℃</li>
	<li>Auxiliary&nbsp;Power (Vaux)&nbsp; : 12V+/-5%, 200mA max &nbsp;</li>
	<li>Operating Temperature: Case Temperature Tc=-30℃~+90℃&nbsp;；10%RH～100%RH &nbsp;</li>
	<li>Storage Temperature: -30℃～+85℃；&nbsp;5%RH～100%RH</li>
	<li>MTBF: ≥350,000 hours, 50℃&nbsp;case &nbsp;temperature (MIL-HDBK-217F)</li>
	<li>Lifetime: ≥100,000 hours, 75℃&nbsp;case &nbsp;temperature, refer to life vs. Tc curve</li>
	<li>Case Temperature: 90℃&nbsp;max, marked in the Tc point of label</li>
	<li>Dimensions: 14.88x1.18x0.82&nbsp;by inch, 378 x 30 x 21&nbsp;by mm &nbsp;</li>
</ul>
Notes:&nbsp;&nbsp;Unless specified, all the test results are measured in 25℃&nbsp;room temperature.
* marked items&nbsp;are optional and contact with sales people to get the functions.
&nbsp;

&nbsp;Features:

<ul>
	<li>Supply Voltage: 90-305Vac or 127-250Vdc</li>
	<li>100,000Hour Life @ Tc=75C</li>
	<li>5 Year Warranty</li>
	<li>AirsetTM&nbsp;NFC Programmability</li>
	<li>1% 0-10V/PWM/Time/DALI Dimmable</li>
	<li>Isolated Dimming Input</li>
	<li>Dim Off with 0.5W Standby Power (Optional)</li>
	<li>12V 300mA Auxiliary Power (Optional)</li>
	<li>Low Inrush Current</li>
	<li>Class II (Optional)</li>
	<li>UL Type TL, Class 2</li>
	<li>ENEC/CB/CCC SELV Output</li>
	<li>Safety according to EN 61347-1, 61347-2-3,&nbsp;61347-2-13, 62384</li>
</ul>
Technical Data :

<ul>
	<li>Input Voltage: 90～305Vac&nbsp;or 127V-250Vdc</li>
	<li>Input Frequency: 47～63Hz</li>
	<li>Power Factor: &gt;0.9@60-100%load, refer to PF vs. Load curve</li>
	<li>THD: &lt;15%@60-100%load, refer to THD vs. Load curve</li>
	<li>Input Current: 1.8 Amax@110Vac &amp; Full-Load, 0.9Amax@220Vac &amp; Full-Load</li>
	<li>Inrush Current: 2A peak, 1.2ms duration, &lt;0.025A2s@230Vac, Cold Start; 4A peak, 1.3ms duration, &lt;0. 05A2s@277Vac, Cold Start</li>
	<li>Leakage Current: 1mA&nbsp;max @277Vac 60Hz, UL8750, 0.75mAmax @220Vac 50Hz, IEC61347-1</li>
	<li>Input Under Voltage: Shut down&nbsp;and auto-recovery</li>
	<li>Surge Protection: Line to line 2kV, line to ground 4kV, IEC 61000-4-5</li>
	<li>Current Accuracy: ±5%Io</li>
	<li>Ripple Current: Ip-p:5%Io max</li>
	<li>Setup Time: 1.2s max</li>
	<li>Overshoot: 10%&nbsp;Io max &amp; LED Load</li>
	<li>Output Over Voltage: 120% Vomax, typ.</li>
	<li>Short Circuit: Auto recovery. The output recovers when short is removed.</li>
	<li>Over Temperature: Lower the output current when Tc≧105±10℃; Auto Recovery When Tc≦70±10℃</li>
	<li>Auxiliary&nbsp;Power (Vaux)&nbsp; : 12V+/-5%, 300mA max &nbsp;</li>
	<li>Operating Temperature: Case Temperature Tc=-30℃~+90℃&nbsp;；10%RH～100%RH &nbsp;</li>
	<li>Storage Temperature: -30℃～+85℃；&nbsp;5%RH～100%RH</li>
	<li>MTBF: ≥350,000 hours, 50℃&nbsp;case &nbsp;temperature (MIL-HDBK-217F)</li>
	<li>Lifetime: ≥100,000 hours, 75℃&nbsp;case &nbsp;temperature, refer to life vs. Tc curve</li>
	<li>Case Temperature: 90℃&nbsp;max, marked in the Tc point of label</li>
	<li>Dimensions: 14.17x1.15x1.00&nbsp;by inch; 360.0x29.4x25.4&nbsp;by mm &nbsp;</li>
</ul>

Notes:&nbsp;&nbsp;Unless specified, all the test results are measured in 25℃&nbsp;room temperature.
&nbsp;* marked items&nbsp;are optional and contact with sales people to get the functions.
&nbsp;

Features:

<ul>
	<li>Supply Voltage: 90-305Vac or 127-420Vdc, 380Vac for 2 hours</li>
	<li>Great Surge Immunity 10kV</li>
	<li>-55℃Cold Ambient Startup (Optional)</li>
	<li>100,000Hour Life @ Tc=75℃</li>
	<li>7 Year Warranty @ Tc&lt;=75℃</li>
	<li>AirsetTM NFC Programmability</li>
	<li>+/-2% Output Current Accuracy (Programmable Model)</li>
	<li>0-10V/PWM/Time/DALI /DMX (Optional) Dimmable</li>
	<li>Dim Off with 0.5W Standby Power</li>
	<li>12V 300mA Auxiliary Power to Power Controllers and Fans (Optional)</li>
	<li>Input Over Voltage Protection (Optional)</li>
	<li>UL Class P, ENEC/CB/CCC SELV Output</li>
	<li>Safety according to EN 61347-1, 61347-2-3, 61347-2-13, 62384</li>
</ul>
Technical Data :

<ul>
	<li>Input Voltage: 90～305Vac&nbsp;or 127V-420Vdc, 380Vac for 2 hours</li>
	<li>Input Frequency: 47～63Hz</li>
	<li>Power Factor: &gt;0.9@60-100%load, refer to PF vs. Load curve</li>
	<li>THD: &lt;15%@60-100%load, refer to THD vs. Load curve</li>
	<li>Input Current: 0.95Amax@120Vac &amp; Full-Load, 0.48Amax@220Vac &amp; Full-Load</li>
	<li>Inrush Current: 65A peak, 1.2ms duration, &lt;0.25A2s@230Vac, Cold Start; 70A peak, 1.3ms duration, &lt;0. 5A2s@277Vac, Cold Start</li>
	<li>Leakage Current: 1mA&nbsp;max @277Vac 60Hz, UL8750,0.75mAmax @220Vac 50Hz, IEC61347-1</li>
	<li>Input Under Voltage: Shut down&nbsp;and auto-restart</li>
	<li>Input Over Voltage: *Optional: Shutdown @320Vac</li>
	<li>Surge Protection: Line to line 6kV, line to ground 10kV, IEC 61000-4-5</li>
	<li>Current Accuracy: ±5%Io</li>
	<li>Ripple Current: Ip-p:5%Io max</li>
	<li>Setup Time: 1.2s max</li>
	<li>Overshoot: 10%&nbsp;Io max &amp; LED Load</li>
	<li>Output Over Voltage: 120% Vomax, typ.</li>
	<li>Short Circuit: Auto recovery. The output recovers when short is removed.</li>
	<li>Over Temperature: Lower the output current when Tc≧110±5℃; Auto Recovery When Tc≦70±5℃</li>
	<li>Auxiliary&nbsp;Power (Vaux)&nbsp; : 12V+/-5%, 300mA max &nbsp;</li>
	<li>Operating Temperature: -40℃～+70℃&nbsp;；10%RH～100%RH</li>
	<li>Storage Temperature: -40℃～+85℃；&nbsp;5%RH～100%RH</li>
	<li>MTBF: ≥320,000 hours, 75℃&nbsp;case &nbsp;temperature (MIL-HDBK-217F)</li>
	<li>Lifetime: ≥100,000 hours, 75℃&nbsp;case &nbsp;temperature, refer to life vs. Tc curve</li>
	<li>Case Temperature: 90℃&nbsp;max, marked in the Tc point of label</li>
	<li>Dimensions: 6.34x2.66x1.32&nbsp;by inch&nbsp;(body), &nbsp;&nbsp;7.40x2.66x1.32&nbsp;by inch&nbsp;(endcaps included); 161.0x67.5x33.5&nbsp;by mm (body), 188.0x67.5x33.5&nbsp;by mm (endcaps included)</li>
	<li>Net Weight: 800g</li>
	<li>Packing: 25pcs, 21kg&nbsp;per carton, carton size: 490x370x230mm</li>
</ul>
Notes:&nbsp;&nbsp;Unless specified, all the test results are measured in 25℃&nbsp;room temperature.
* marked items&nbsp;are optional and contact with sales people to get the functions.
&nbsp;

Features:

<ul>
	<li>Supply Voltage: 90-305Vac or 127-420Vdc, 380Vac for 2 hours</li>
	<li>Great Surge Immunity 10kV</li>
	<li>-55℃Cold Ambient Startup (Optional)</li>
	<li>100,000Hour Life @ Tc=75℃</li>
	<li>7 Year Warranty @ Tc&lt;=75℃</li>
	<li>AirsetTM NFC Programmability</li>
	<li>+/-2% Output Current Accuracy (Programmable Model)</li>
	<li>0-10V/PWM/Time/DALI /DMX (Optional) Dimmable</li>
	<li>Dim Off with 0.5W Standby Power</li>
	<li>12V 300mA Auxiliary Power to Power Controllers and Fans (Optional)</li>
	<li>Input Over Voltage Protection (Optional)</li>
	<li>UL Class P, ENEC/CB/CCC SELV Output</li>
	<li>Safety according to EN 61347-1, 61347-2-3, 61347-2-13, 62384</li>
</ul>
Technical Data :

<ul>
	<li>Input Voltage: 90～305Vac&nbsp;or 127V-420Vdc, 380Vac for 2 hours</li>
	<li>Input Frequency: 47～63Hz</li>
	<li>Power Factor: &gt;0.9@60-100%load, refer to PF vs. Load curve</li>
	<li>THD: &lt;15%@60-100%load, refer to THD vs. Load curve</li>
	<li>Input Current: 1.2 Amax@120Vac &amp; Full-Load, 0.6Amax@220Vac &amp; Full-Load</li>
	<li>Inrush Current: 65A peak, 1.2ms duration, &lt;0.25A2s@230Vac, Cold Start; 70A peak, 1.3ms duration, &lt;0. 5A2s@277Vac, Cold Start</li>
	<li>Leakage Current: 1mA&nbsp;max @277Vac 60Hz, UL8750,0.75mAmax @220Vac 50Hz, IEC61347-1</li>
	<li>Input Under Voltage: Shut down&nbsp;and auto-restart</li>
	<li>Input Over Voltage: *Optional: Shutdown @320Vac</li>
	<li>Surge Protection: Line to line 6kV, line to ground 10kV, IEC 61000-4-5</li>
	<li>Current Accuracy: ±5%Io</li>
	<li>Ripple Current: Ip-p:5%Io max</li>
	<li>Setup Time: 1.2s max</li>
	<li>Overshoot: 10%&nbsp;Io max &amp; LED Load</li>
	<li>Output Over Voltage: 120% Vomax, typ.</li>
	<li>Short Circuit: Auto recovery. The output recovers when short is removed.</li>
	<li>Over Temperature: Lower the output current when Tc≧105±10℃; Auto Recovery When Tc≦70±10℃</li>
	<li>Auxiliary&nbsp;Power (Vaux)&nbsp; : 12V+/-5%, 300mA max &nbsp;</li>
	<li>Operating Temperature: -40℃～+70℃&nbsp;；10%RH～100%RH</li>
	<li>Storage Temperature: -40℃～+85℃；&nbsp;5%RH～100%RH</li>
	<li>MTBF: ≥320,000 hours, 75℃&nbsp;case &nbsp;temperature (MIL-HDBK-217F)</li>
	<li>Lifetime: ≥100,000 hours, 75℃&nbsp;case &nbsp;temperature, refer to life vs. Tc curve</li>
	<li>Case Temperature: 90℃&nbsp;max, marked in the Tc point of label</li>
	<li>Dimensions: 6.34x2.66x1.32&nbsp;by inch&nbsp;(body), &nbsp;&nbsp;7.40x2.66x1.32&nbsp;by inch&nbsp;(endcaps included); 161.0x67.5x33.5&nbsp;by mm (body), 188.0x67.5x33.5&nbsp;by mm (endcaps included)</li>
	<li>Net Weight: 800g</li>
	<li>Packing: 25pcs, 21kg per carton, carton size: 490x370x230mm</li>
</ul>
Notes:&nbsp;&nbsp;Unless specified, all the test results are measured in 25℃&nbsp;room temperature.
* marked items&nbsp;are optional and contact with sales people to get the functions.
&nbsp;

Features:

<ul>
	<li>Supply Voltage: 90-305Vac or 127-420Vdc, 380Vac for 2 hours</li>
	<li>Great Surge Immunity 10kV</li>
	<li>-55℃Cold Ambient Startup (Optional)</li>
	<li>100,000Hour Life @ Tc=75℃</li>
	<li>7 Year Warranty @ Tc&lt;=75℃</li>
	<li>AirsetTM NFC Programmability</li>
	<li>+/-2% Output Current Accuracy (Programmable Model)</li>
	<li>0-10V/PWM/Time/DALI /DMX (Optional) Dimmable</li>
	<li>Dim Off with 0.5W Standby Power</li>
	<li>12V 300mA Auxiliary Power to Power Controllers and Fans (Optional)</li>
	<li>Input Over Voltage Protection (Optional)</li>
	<li>UL Class P, ENEC/CB/CCC SELV Output</li>
	<li>Safety according to EN 61347-1, 61347-2-3, 61347-2-13, 62384</li>
</ul>
Technical Data :

<ul>
	<li>Input Voltage: 90～305Vac&nbsp;or 127V-420Vdc, 380Vac for 2 hours</li>
	<li>Input Frequency: 47～63Hz</li>
	<li>Power Factor: &gt;0.9@60-100%load, refer to PF vs. Load curve</li>
	<li>THD: &lt;15%@60-100%load, refer to THD vs. Load curve</li>
	<li>Input Current: 0.58Amax@120Vac &amp; Full-Load, 0.31Amax@220Vac &amp; Full-Load</li>
	<li>Inrush Current: 65A peak, 1.2ms duration, &lt;0.25A2s@230Vac, Cold Start; 70A peak, 1.3ms duration, &lt;0. 5A2s@277Vac, Cold Start</li>
	<li>Leakage Current: 1mA&nbsp;max @277Vac 60Hz, UL8750, 0.75mAmax @220Vac 50Hz, IEC61347-1</li>
	<li>Input Under Voltage: Shut down&nbsp;and auto-recovery</li>
	<li>Input Over Voltage: *Optional: Shutdown @320Vac</li>
	<li>Surge Protection: Line to line 6kV, line to ground 10kV, IEC 61000-4-5</li>
	<li>Current Accuracy: ±5%Io</li>
	<li>Ripple Current: Ip-p:5%Io max</li>
	<li>Setup Time: 1.2s max</li>
	<li>Overshoot: 10%&nbsp;Io max &amp; LED Load</li>
	<li>Output Over Voltage: 120% Vomax, typ.</li>
	<li>Short Circuit: Auto recovery. The output recovers when short is removed.</li>
	<li>Over Temperature: Lower the output current when Tc≧105±10℃; Auto Recovery When Tc≦70±10℃</li>
	<li>Auxiliary&nbsp;Power (Vaux) : 12V+/-5%, 300mA max &nbsp;</li>
	<li>Operating Temperature: -40℃～+70℃&nbsp;；10%RH～100%RH</li>
	<li>Storage Temperature: -40℃～+85℃；&nbsp;5%RH～100%RH</li>
	<li>MTBF: ≥320,000 hours, 50℃&nbsp;case &nbsp;temperature (MIL-HDBK-217F)</li>
	<li>Lifetime: ≥100,000 hours, 75℃&nbsp;case &nbsp;temperature, refer to life vs. Tc curve</li>
	<li>Case Temperature: 90℃&nbsp;max, marked in the Tc point of label</li>
	<li>Dimensions: 5.16x2.66x1.32&nbsp;by inch&nbsp;(body), &nbsp;&nbsp;6.22x2.66x1.32&nbsp;by inch&nbsp;(endcaps included); 131.0x67.5x33.5&nbsp;by mm (body), 158.0x67.5x33.5&nbsp;by mm (endcaps included)</li>
	<li>Net Weight: 600g</li>
	<li>Packing: 25pcs/Carton/17.3kg, 490x370x230mm</li>
</ul>
Notes:&nbsp;&nbsp;Unless specified, all the test results are measured in 25℃&nbsp;room temperature.
* marked items&nbsp;are optional and contact with sales people to get the functions.
&nbsp;
