Contrast Lighting Ardito 2.5IN Recessed Flangeless Trim LED Downlight | Lights | Indoor Lighting
Contrast Lighting Ardito 2.5IN Recessed Flangeless Trim LED Downlight
Mainland China
Booth: 5B-F08 | LED Lighting |
Product Specification
Control

DMX-RDM

Brand

Liteharbor

Material

Aluminum

Model No.

Ardito Series

Customised

Yes

Lighting Style

Modern

Pattern

Rouns and Square

CCT Tunable

Warm Dimming, CCT Changeable

Is Dimmable

Yes

Feature

Adjustable

Size

2.5‘’,3.5‘’,4‘’

Solution

PoE Solution

Wattage

Performance 1 (14W), Performance 2 (23W)

Product Description

Description

Ultra-Thin Profile Round Adjustable Regressed Trim, 2-1/2" high-efficiency dimmable LED downlight allowing up to 30° tilt adjustable from below ceiling. Offered in Remodel NON-IC (with optional mounting plate), new construction NON-IC and new construction IC configurations.

LIGHT ENGINE

STANDARD (SOLID WHITE)

Lumileds Luxeon CoB 1203 GEN3.

L70 @ 50,000 hours of operation.

3-Step MacAdam ellipse (3 SDCM)

Color Temperatures: 2,700K - 3,000K - 3,500K - 4,000K

CRI: 90+

R9: >50

Delivered Lumens: Performance 1 (14W) up to 1,375 lumens (95 lm/W)

Power Supply: 120V / 277V (universal input)

One driver available in performance 1 (14W) and offering 2 dimming options within the same unit:

ELV: 120V only

0-10V: 120V / 277V

Consult housing specification sheet for more details.

WARM DIMMING (WD)

LED module mimicking the halogen lamp dimming conditions by lowering color temperature from 3,050K at full intensity down to 1,800K at low-end

while ensuring 94+ CRI throughtout the whole process.

L70 @ 50,000 hours of operation.

3-Step MacAdam ellipse (3 SDCM)

Color Temperatures: 3,050K to 1,800K

CRI: 94+ (over the entire dimming range)

R9: >85

Delivered Lumens: Performance 1 (14W) 775 lumens @ 3,000K (55 lm/W)

Power Supply: 120V / 277V (universal input)

One driver available in performance 1 (14W) and offering 2 dimming options within the same unit:

ELV: 120V only

0-10V: 120V / 277V

Consult housing specification sheet for more details.

OPTIC SYSTEM

Interchangeable optional optical reflectors and lenses available to customize your lighting.

Choice of available lenses:

(also sold separately)

Clear (C)

Frosted (F)

Honeycomb (H): the honeycomb louver reduces glare

Linear (L): the linear lens directs the lamp beam to create a strip of light

Prismatic (P): the prismatic lens diffuses and spreads the light in an even overall pattern

Solite (S): the solite lens softens the light in an even overall pattern

Optical reflectors available: Spot, Narrow Flood, Flood and Wide Flood

Average beams shown. Consult .ies files on our Web site for more details.

FLANGE AND REFLECTOR

FINISHES

Powder coat painted or plated die formed steel.

Different finishes available: (Options in red may generate a longer production lead time)

24K Gold Plated (-03), Chrome (-04), Brushed Chrome (-04BR), Matte White (-11), Brushed Nickel (-12BR), Satin Nickel (-13), Matte Black (-22)

and Polar Grey (-25)

FLANGELESS TRIMS

(OPTION)

Perforated aluminum plate for flangeless product, allowing you to plaster up to the edge of the opening of the Ardito luminaire.

Mud-in-plate sold separetely.

Consult housing specification sheet for more details.

Standard

12° Spot (S), 24° Narrow Flood (M), 36° Flood (L), 60°  Wide Flood (V)


Production Lead Time

35 days
