    High-Efficacy Free-Cutting Series - 150lm/W 12V 160LED/M - 9680
    General Lighting Innovation Limited
    香港
    展位編號: 5B-E20 | LED照明 |
    產品規格
    Increment

    6.25mm [0.25in.] (The minimum length for use is 6.25mm[0.25in.] with 1 LED)

    Beam Angle

    120°

    CCT/Wavelength

    2700/3000/3500/4000/5000/6500K (3 step in one bin)

    LED Type

    SMD 2835

    Power

    7.2W/M [2.2W/ft.]

    Part No.

    GL-N2835XX-12-CV-160-9680

    Light Efficiency@CRI90&4000K

    150lm/W

    Dimension

    L3000*W5*H1.5mm [L118*W0.2*H0.06in.]

    Voltage

    12VDC

    Brightness@CRI90&4000K

    1080lm/M [329lm/ft.]

    IP Rating

    IP20/IP65 [Dry/Wet]

    LED Qty

    160LED/M [48LED/ft.]

    產品簡介
    Features
    -

    1. Field cuttable per one LED to be any length for precise assembly.
    2. High efficacy up to 150lm/W in CRI90 with energy efficiency class in D.
    3. Universal PCB width for perfect installation with aluminum profile.
    4. High density of LED array for dot-free linear lighting performance.

    Details
    -

    Application

    Indirect lighting for showcase, shelf, cabinet, billboard, signage, hotel, garden, bridge, corridor, ceiling, stair, cove, theatre, lift etc.
