    10.1inch TFT LCD screen 1280*800 RGB LCD module 600nits LVDS interface
    Microtech Technology Company Limited
    香港
    |
    生产线所在地：中国内地
    展位编号: 5B-D08 | 显示技术世界 |
    产品规格
    型号编号

    MTF101IA-01B

    品牌

    Microtech

    尺寸

    10.1inch

    是否可订造

    可以

    产品简介
    No.
    Item
    Specification
    Remark
    1
    LCD size
    10.1 inch(Diagonal)

    2
    Driver element
    a-Si TFT active matrix

    3
    Resolution
    1280 x 800

    4
    Display mode
    Normally Black, Transmissive

    5
    Dot pitch
    0.0565(W) x 0.1695(H) mm

    6
    Active area
    216.96(W) x 135.60(H) mm

    7
    Panel size
    229.26(W) x148.9(H) x2.5(D) mm
    Note 1
    8
    Surface treatment
    HC

    9
    Color arrangement
    RGB-stripe

    10
    Interface
    LVDS

    11
    Viewdirection(Gray Inversion)
    free

    12
    Panel power consumption
    0.7W (Typ)
    Note 2
    13
    Weight
    80g(Typ)

    14
    Brightness
    600 cd/m2

    Note 1: Refer to Mechanical Drawing.

    Note 2: Including T-con Board power consumption


    生产所需时间

    25-45 日
